BisCore (BIS Core) Schema
Alias: bis
Version: 1.0.16
The BIS core schema contains classes that all other domain schemas extend.
BisCore contains the core classes that define the fundamental building-blocks of BIS (e.g. Models, Elements, and ElementAspects) and which specialize them to establish domain-neutral base-classes for modeling the real world from multiple Modeling Perspectives.
BisCore also contains some less-fundamental classes related to infrastructure engineering visualization and documentation in general, such as drawings, views, etc.
The core classes are decorated by ECCustomAttributes that effectively define the database schema mapping for an iModel, but which can be ignored for other kinds of BIS Repositories. Other schemas cannot alter the underlying database schema mapping without explicit permission from BisCore.
The classes of BisCore are used as base classes for all classes in other BIS Domain schemas.
See Base Infrastructure Schemas
Table of contents
- Entity Classes
- AnnotationElement2d
- AnnotationFrameStyle
- AnnotationLeaderStyle
- AnnotationTextStyle
- AuxCoordSystem
- AuxCoordSystem2d
- AuxCoordSystem3d
- AuxCoordSystemSpatial
- Category
- CategorySelector
- ChannelRootAspect
- CodeSpec
- ColorBook
- DefinitionContainer
- DefinitionElement
- DefinitionGroup
- DefinitionModel
- DefinitionPartition
- DefinitionSet
- DictionaryModel
- DisplayStyle
- DisplayStyle2d
- DisplayStyle3d
- Document
- DocumentCarrier
- DocumentListModel
- DocumentPartition
- Drawing
- DrawingCategory
- DrawingGraphic
- DrawingModel
- DrawingViewDefinition
- DriverBundleElement
- Element
- ElementAspect
- ElementMultiAspect
- ElementUniqueAspect
- EmbeddedFileLink
- ExternalSource
- ExternalSourceAspect
- ExternalSourceAttachment
- ExternalSourceGroup
- FolderLink
- GeometricElement
- GeometricElement2d
- GeometricElement3d
- GeometricModel
- GeometricModel2d
- GeometricModel3d
- GeometryPart
- GraphicalElement2d
- GraphicalElement3d
- GraphicalModel2d
- GraphicalModel3d
- GraphicalPartition3d
- GraphicalType2d
- GroupInformationElement
- GroupInformationModel
- GroupInformationPartition
- InformationCarrierElement
- InformationContentElement
- InformationModel
- InformationPartitionElement
- InformationRecordElement
- InformationRecordModel
- InformationRecordPartition
- InformationReferenceElement
- LightLocation
- LineStyle
- LinkElement
- LinkModel
- LinkPartition
- Model
- ModelSelector
- OrthographicViewDefinition
- PhysicalElement
- PhysicalMaterial
- PhysicalModel
- PhysicalPartition
- PhysicalPortion
- PhysicalSystem
- PhysicalSystemModel
- PhysicalSystemPartition
- PhysicalType
- RecipeDefinitionElement
- RenderMaterial
- RenderTimeline
- RepositoryLink
- RepositoryModel
- RoleElement
- RoleModel
- SectionDrawing
- SectionDrawingLocation
- SectionDrawingModel
- SectionLocation
- Sheet
- SheetBorder
- SheetBorderTemplate
- SheetIndex
- SheetIndexEntry
- SheetIndexFolder
- SheetIndexModel
- SheetIndexPartition
- SheetIndexReference
- SheetModel
- SheetReference
- SheetTemplate
- SheetViewDefinition
- SpatialCategory
- SpatialElement
- SpatialIndex
- SpatialLocationElement
- SpatialLocationModel
- SpatialLocationPartition
- SpatialLocationPortion
- SpatialLocationType
- SpatialModel
- SpatialViewDefinition
- SubCategory
- Subject
- SynchronizationConfigLink
- TemplateRecipe2d
- TemplateRecipe3d
- TemplateViewDefinition2d
- TemplateViewDefinition3d
- TextAnnotation2d
- TextAnnotation3d
- TextAnnotationData
- TextAnnotationSeed
- Texture
- TypeDefinitionElement
- UrlLink
- ViewAttachment
- ViewDefinition
- ViewDefinition2d
- ViewDefinition3d
- VolumeElement
- WebMercatorModel
- Mixins
- Custom Attribute Classes
- Relationship Classes
- BaseModelForView2d
- CategoryOwnsSubCategories
- CategorySelectorRefersToCategories
- CodeSpecSpecifiesCode
- DefinitionGroupGroupsDefinitions
- DrawingGraphicRepresentsElement
- DrawingModelBreaksDownDrawing
- ElementDrivesElement
- ElementEncapsulatesElements
- ElementGroupsMembers
- ElementHasLinks
- ElementIsFromSource
- ElementOwnsChannelRootAspect
- ElementOwnsChildElements
- ElementOwnsExternalSourceAspects
- ElementOwnsMultiAspects
- ElementOwnsUniqueAspect
- ElementRefersToDocuments
- ElementRefersToElements
- ElementScopesCode
- ElementScopesExternalSourceIdentifier
- ExternalSourceAttachmentAttachesSource
- ExternalSourceGroupGroupsSources
- ExternalSourceIsInRepository
- ExternalSourceOwnsAttachments
- FolderContainsRepositories
- GeometricElement2dHasTypeDefinition
- GeometricElement2dIsInCategory
- GeometricElement3dHasTypeDefinition
- GeometricElement3dIsInCategory
- GraphicalElement2dIsOfType
- GraphicalElement3dRepresentsElement
- GraphicalType2dHasTemplateRecipe
- GroupImpartsToMembers
- ModelContainsElements
- ModelModelsElement
- ModelOwnsSubModel
- ModelSelectorRefersToModels
- PartitionOriginatesFromRepository
- PhysicalElementAssemblesElements
- PhysicalElementIsOfPhysicalMaterial
- PhysicalElementIsOfType
- PhysicalModelBreaksDownPhysicalPortion
- PhysicalSystemAggregatesSubSystems
- PhysicalSystemGroupsMembers
- PhysicalSystemServicesSpatialElements
- PhysicalTypeHasTemplateRecipe
- PhysicalTypeIsOfPhysicalMaterial
- RenderMaterialOwnsRenderMaterials
- SectionDrawingGeneratedFromSpatialView
- SectionDrawingLocationRefersToSectionView
- SectionLocationRefersToViewAttachment
- SectionLocationUsesCategorySelector
- SectionLocationUsesModelSelector
- SheetBorderHasSheetBorderTemplate
- SheetHasSheetTemplate
- SheetIndexFolderOwnsEntries
- SheetIndexOwnsEntries
- SheetIndexReferenceRefersToSheetIndex
- SheetModelBreaksDownSheet
- SheetReferenceRefersToSheet
- SheetTemplateHasSheetBorder
- SpatialLocationIsOfType
- SpatialViewDefinitionUsesModelSelector
- SubjectOwnsPartitionElements
- SubjectOwnsSubjects
- SubjectRefersToSubject
- SynchronizationConfigProcessesSources
- SynchronizationConfigSpecifiesRootSources
- TextAnnotation2dOwnsTextAnnotationData
- TextAnnotation3dOwnsTextAnnotationData
- TypeDefinitionHasRecipe
- ViewDefinitionUsesCategorySelector
- ViewDefinitionUsesDisplayStyle
- ViewIsAttached
- Enumerations
Entity Classes
AnnotationElement2d (2D Annotation Element) EntityClass
bis:AnnotationElement2d is a bis:GraphicalElement2d used to annotate drawings and sheets.
Base Class: BisCore:GraphicalElement2d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:DrawingCategory used to categorize this bis:GeometricElement2d instance. | navigation | |
| Origin | The placement origin of this bis:Element. | point2d | |
| Rotation | The placement rotation (in degrees) of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point2d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point2d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than by instance of this Element. | navigation |
AnnotationFrameStyle (Annotation Frame Style) Sealed EntityClass
Base Class: BisCore:DefinitionElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Description | Description of the style | string | |
| Data | Encoded style properties | binary |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
AnnotationLeaderStyle (Annotation Leader Style) Sealed EntityClass
Base Class: BisCore:DefinitionElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Description | Description of the style | string | |
| Data | Encoded style properties | binary |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
AnnotationTextStyle (Annotation Text Style) Sealed EntityClass
Base Class: BisCore:DefinitionElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Description | Description of the style | string | |
| Data | Encoded style properties | binary |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
AuxCoordSystem (Auxiliary Coordinate System) Abstract EntityClass
Base Class: BisCore:DefinitionElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Type | See the ACSType enum. None = 0; Rectangular = 1; Cylindrical = 2; Spherical = 3. | int | |
| Description | A human-readable description of the Auxiliary Coordinate System | string |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
AuxCoordSystem2d (2D Auxiliary Coordinate System) EntityClass
A 2D coordinate system.
Base Class: BisCore:AuxCoordSystem
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Origin | Defines the real location of the 0, 0 coordinate of the ACS. | point2d | |
| Angle | The angle (in degrees) of the Coordinate System | double |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Type | See the ACSType enum. None = 0; Rectangular = 1; Cylindrical = 2; Spherical = 3. | int | |
| Description | A human-readable description of the Auxiliary Coordinate System | string |
AuxCoordSystem3d (3D Auxiliary Coordinate System) EntityClass
A 3D coordinate system.
Base Class: BisCore:AuxCoordSystem
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Origin | Defines the plane of the ACS and the real location of the 0, 0, 0 coordinate of the ACS. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this Coordinate System | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this Coordinate System | double | |
| Roll | The Roll angle (in degrees) of the orientation of this Coordinate System | double |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Type | See the ACSType enum. None = 0; Rectangular = 1; Cylindrical = 2; Spherical = 3. | int | |
| Description | A human-readable description of the Auxiliary Coordinate System | string |
AuxCoordSystemSpatial (Spatial Auxiliary Coordinate System) EntityClass
A spatial coordinate system.
Base Class: BisCore:AuxCoordSystem3d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Type | See the ACSType enum. None = 0; Rectangular = 1; Cylindrical = 2; Spherical = 3. | int | |
| Description | A human-readable description of the Auxiliary Coordinate System | string | |
| Origin | Defines the plane of the ACS and the real location of the 0, 0, 0 coordinate of the ACS. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this Coordinate System | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this Coordinate System | double | |
| Roll | The Roll angle (in degrees) of the orientation of this Coordinate System | double |
Category Abstract EntityClass
A bis:Category categorizes a bis:GeometricElement and its geometry. Every bis:GeometricElement is in one and only one bis:Category. The visibility (on/off) of a bis:Category may be controlled per-view. Categories are similar to levels in DGN, layers in DWG, and categories in RVT.
Base Class: BisCore:DefinitionElement
Categories should be standardized by domain groups where possible. They generally correlate with groups of BIS Element classes, or a single base class.
Also see the ClassificationSystems domain schema for another way of categorizing and classifying elements.
Behavior: The system handler (C++) for
Categoryrequires a validCodeValue(name) for every instance. It will insert a defaultSubCategoryfor everyCategorythat is inserted. The system handler also restricts deletion. ACategorycan only be deleted via a more expensivedeleteDefinitionElementsmethod that has determined theCategoryis no longer referenced.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Description | A human-readable description of the Category | string | |
| Rank | The Rank of a category indicates how it was created and where it can be used. 0=System; 1=Domain; 2=Application; 3=User. | int |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
CategorySelector (Category Selector) EntityClass
Specifies the list of categories displayed by a ViewDefinition. Multiple ViewDefinitions may point to the same CategorySelector.
Base Class: BisCore:DefinitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
Behavior: The system handler restricts deletion. A
CategorySelectorcan only be deleted via a more expensivedeleteDefinitionElementsmethod that has determined theCategorySelectoris no longer referenced.
ChannelRootAspect (Channel Root Aspect) Sealed EntityClass
A bis:ElementUniqueAspect that identifies a bis:Element as the root of a channel which is a subset of the overall iModel hierarchy that is independently maintained.
Base Class: BisCore:ElementUniqueAspect
Applications create channels to define portions of the model-hierarchy that they "own".
Each Element (typically a Subject or InformationPartitionElement) that owns a ChannelRootAspect defines a root of the model-hierarchy that is included in a particular channel. It recursively descends down through ElementOwnsChildElements and ModelModelsElement relationships to include all of the child elements and sub-models into the specified channel. A channel is conceptually identified by its Channel Key value of the Owner property of a ChannelRootAspect.
There may be more than one root Subjects or InformationPartitionElements in a model-hierarchy that are included in the same channel. In that case, each Subject or InformationPartitionElement instance specifies the same Channel Key value in their ChannelRootAspect.
Note that Channels do not nest. That is, once a Subject or InformationPartitionElement instance defines a root to be included in a particular channel, no descendant Element of such root in the subject-hierarchy can be used to define a root for a different channel.
See Channels for more information on the topic.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Owner | The owner of the channel | string |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Element | The bis:Element that owns this bis:ElementUniqueAspect | navigation |
CodeSpec (Code Specification) Sealed EntityClass
A bis:CodeSpec (code specification) captures the rules for encoding and decoding significant business information into and from a Code (string). This specification is used to generate and validate Codes.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Name | The unique name of the bis:CodeSpec. A best practice is to incorporate the schema alias or domain name into the bis:CodeSpec name to ensure uniqueness. | string | |
| JsonProperties | A JSON string containing scope and fragment specifications used to generate and validate code values | string | Json |
ColorBook (Color Book) Sealed EntityClass
Base Class: BisCore:DefinitionElement
Individual colors are stored in JsonProperties
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Description | A human-readable description of the ColorBook | string |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
DefinitionContainer (Definition Container) EntityClass
A set of DefinitionElements that are exclusively owned by the DefinitionContainer and contained within its sub-model.
Base Class: BisCore:DefinitionSet
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
DefinitionContainer represents a DefinitionSet that exclusively owns its DefinitionElements. The exclusivity is only effective relative to other DefinitionContainers (or similar DefinitionElements that have sub-models); the DefinitionElements that are contained in a DefinitionContainer may also be in one or more DefinitionGroups.
See DefinitionSet documentation for recursive interpretations of DefinitionSets containing DefinitionSets.
A DefinitionContainer can conceptually be thought of as a folder of definitions.
A DefinitionContainer is recommended when there is a standard set of domain-specific definitions that must be known to domain software applications.
In this case, the DefinitionContainer should be contained by the DictionaryModel and found by the software via a known Code.
DefinitionElement (Definition Element) Abstract EntityClass
A bis:DefinitionElement holds configuration-related information that is meant to be referenced/shared.
Base Class: BisCore:InformationContentElement
Behavior: The system handler (C++) for
DefinitionElementwill only permit instances to be inserted into aDefinitionModel.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
DefinitionGroup (Definition Group) EntityClass
A non-exclusive set of DefinitionElements grouped using the DefinitionGroupGroupsDefinitions relationship.
Base Class: BisCore:DefinitionSet
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
DefinitionGroup is intended for defining non-exclusive sets of DefinitionElements (a DefinitionElement may be in multiple DefinitionGroups). DefinitionGroup holds its DefinitionElements through the DefinitionGroupGroupsDefinitions relationship. The referenced DefinitionElements may be contained in the same DefinitionModel as the DefinitionGroup or may be contained in other DefinitionModels.
See DefinitionSet documentation for recursive interpretations of DefinitionSets containing DefinitionSets.
Care must be taken to avoid circular references. Note that even a single DefinitionGroup can create circular references in two cases:
- The
DefinitionGroupdirectly contains itself. - The
DefinitionGroupcontains aDefinitionContainerthat directly or indirectly contains theDefinitionGroup.
DefinitionModel (Definition Model) EntityClass
A container for persisting bis:DefinitionElement instances.
Base Class: BisCore:InformationModel
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime |
Behavior: The system handler (C++) for
DefinitionElementwill only permit instances to be inserted into aDefinitionModel. OtherInformationContentElementinstances can also be inserted into aDefinitionModel.
DefinitionPartition (Definition Partition) Sealed EntityClass
A bis:DefinitionPartition element establishes a 'Definition' Modeling Perspective for its parent bis:Subject. A bis:DefinitionPartition is always sub-modeled by a bis:DefinitionModel.
Base Class: BisCore:InformationPartitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Description | A human-readable string describing the intent behind the partition. | string |
The 'Definition' Modeling Perspective is for modeling definitions of things that are shared by multiple particular Entities.
Behavior: The system handler (C++) for
DefinitionPartitionensures that it is only ever sub-modeled by aDefinitionModel.
DefinitionSet (Definition Set) Abstract EntityClass
This abstract class unifies DefinitionGroup and DefinitionContainer for relationship endpoint purposes.
Base Class: BisCore:DefinitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
DefinitionSet represents a set of DefinitionElements. The set may be exclusive (DefinitionContainer owns its DefinitionElements) or may be non-exclusive (DefinitionGroup does not own its DefinitionElements). DefinitionSet should only be directly subclassed by DefinitionGroup and DefinitionContainer. DefinitionGroup and DefinitionContainer may be further subclassed.
References to DefinitionSets will generally treat the DefinitionSets recursively. If DefinitionSet A contains DefinitionSet B and DefinitionSet C, the members of DefinitionSet B and DefinitionSet C will be considered to be first class members of DefinitionSet A (effectively they will be considered as peers of the DefinitionElements that are directly contained in DefinitionSet A). This recursive interpretation extends through the full depth of nested DefinitionSets.
DictionaryModel (Dictionary Model) Sealed EntityClass
The singleton container for repository-global bis:DefinitionElement instances.
Base Class: BisCore:DefinitionModel
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime |
DisplayStyle (Display Style) Abstract EntityClass
A bis:DisplayStyle defines the 'styling' parameters for rendering the contents of a view. It determines how graphics are rendered, not which elements are rendered. A bis:DisplayStyle can be shared by many Views.
Base Class: BisCore:DefinitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
Behavior: The system handler restricts deletion. A
DisplayStylecan only be deleted via a more expensivedeleteDefinitionElementsmethod that has determined theDisplayStyleis no longer referenced.
DisplayStyle2d (2D Display Style) EntityClass
A bis:DisplayStyle2d defines the 'styling' parameters for rendering the contents of a 2D View.
Base Class: BisCore:DisplayStyle
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
DisplayStyle3d (3D Display Style) EntityClass
A bis:DisplayStyle3d defines the 'styling' parameters for rendering the contents of a 3D View.
Base Class: BisCore:DisplayStyle
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
Document (Document) Abstract EntityClass
A bis:Document is a social artifact designed with the distinct purpose to convey information in a manner that maximizes reach and lifespan and minimize dependency on other artifacts. Although there is often a one-to-one relationship between a bis:Document and an electronic file, this does not imply that a document is a file; instead, a document can be realized in many different media (such as paper) or have more than one file supporting it.
Base Class: BisCore:InformationContentElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
DocumentCarrier (Document Carrier) Abstract EntityClass Deprecated
DEPRECATED: A Document Carrier is an Information Carrier that carries a Document. An electronic file is a good example.
Base Class: BisCore:InformationCarrierElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
DocumentListModel (Document List) EntityClass
A container for persisting bis:Document elements.
Base Class: BisCore:InformationModel
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime |
Behavior: The system handler (C++) for
DocumentListModelwill only permit the insertion ofDocumentinstances. The modeled element for aDocumentListModelis expected to be aDocumentPartition.
DocumentPartition (Document Partition) Sealed EntityClass
A bis:DocumentPartition element establishes a 'Document' Modeling Perspective for its parent bis:Subject. A bis:DocumentPartition is always sub-modeled by a bis:DocumentListModel.
Base Class: BisCore:InformationPartitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Description | A human-readable string describing the intent behind the partition. | string |
The 'Document' Modeling Perspective is a subset of the 'Information' Modeling Perspective. It holds Elements which describes Entities using Documents and is used to create primary documents such as Drawings.
Behavior: The system handler (C++) for
DocumentPartitionensures that it is only ever sub-modeled by anInformationModel(typicallyDocumentListModel).
Drawing EntityClass
A bis:Drawing is a bis:Document of a 2D drawing.
Base Class: BisCore:Document
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
DrawingCategory (Drawing Category) Sealed EntityClass
A bis:DrawingCategory is used for classifying bis:GeometricElement2d elements via the bis:GeometricElement2dIsInCategory (concrete and sealed) relationship.
Base Class: BisCore:Category
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Description | A human-readable description of the Category | string | |
| Rank | The Rank of a category indicates how it was created and where it can be used. 0=System; 1=Domain; 2=Application; 3=User. | int |
DrawingGraphic (Drawing Graphic) EntityClass
bis:DrawingGraphic is a bis:GraphicalElement2d used to persist graphics for use in drawings.
Base Class: BisCore:GraphicalElement2d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:DrawingCategory used to categorize this bis:GeometricElement2d instance. | navigation | |
| Origin | The placement origin of this bis:Element. | point2d | |
| Rotation | The placement rotation (in degrees) of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point2d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point2d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than by instance of this Element. | navigation |
DrawingModel (Drawing Model) EntityClass
A container for persisting bis:DrawingGraphic elements.
Base Class: BisCore:GraphicalModel2d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime | |
| GeometryGuid | A GUID that changes whenever any element in this GeometricModel has a change to its geometry. | binary | BeGuid |
| GlobalOrigin | The actual coordinates of (0,0) in modeling coordinates. An offset applied to all modeling coordinates. | point2d |
Behavior: The system handler (C++) for
DrawingModelensures that the modeled element for aDrawingModelis aDrawingor aTemplateRecipe2d. The restrictions from theGeometricModel2dsuperclass also apply.
DrawingViewDefinition (Drawing View Definition) EntityClass
A bis:DrawingViewDefinition specifies parameters for a view of a bis:DrawingModel.
Base Class: BisCore:ViewDefinition2d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Description | A human-readable description of the View Definition | string | |
| CategorySelector | navigation | ||
| DisplayStyle | navigation | ||
| BaseModel | navigation | ||
| Origin | Lower left corner of the viewed area. | point2d | |
| Extents | Size of the view diagonal | point2d | |
| RotationAngle | Rotation angle in degrees of the viewed area. | double |
DriverBundleElement (Driver Bundle Element) Abstract EntityClass
A bis:DriverBundleElement is used in conjunction with bis:ElementDrivesElement relationships to bundle multiple inputs before driving the output bis:Element.
Base Class: BisCore:InformationContentElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
Used when multiple inputs for a "driving" relationship cannot be considered in isolation.
See ElementDrivesElement.
Element Abstract EntityClass
A bis:Element is the smallest individually identifiable building block for modeling the real world. Each bis:Element represents an Entity in the real world. Sets of bis:Elements (contained in bis:Models) are used to sub-model other bis:Elements that represent larger scale real world Entities. Using this recursive modeling strategy, bis:Elements can represent Entities at any scale. Elements can represent physical things, abstract concepts or simply be information records.
Sets of bis:Elements (contained in bis:Models) are used to sub-model other bis:Elements that represent larger scale real world Entities. Using this recursive modeling strategy, bis:Elements can represent Entities at any scale. Elements can represent physical things, abstract concepts or simply be information records.
See Element Fundamentals.
Behavior: System handlers (written in C++) and domain handlers (written in TypeScript) provide behavior to specific
Elementsubclasses. The system handler forElementrequires a validModelreference and a valid or emptyCode. If theParentproperty is notNULL, the system handler also requires that the child Element be in the same Model as the parent Element. This is enforced for allElementsubclasses.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
ElementAspect (Element Aspect) Abstract EntityClass
A bis:ElementAspect is a class that defines a set of properties that are related to (and owned by) a single bis:Element. Semantically, a bis:ElementAspect can be considered part of the bis:Element. Thus, a bis:ElementAspect is deleted if its owning bis:Element is deleted.
ElementMultiAspect (Element Multi-Aspect) Abstract EntityClass
A bis:ElementMultiAspect is a bis:ElementAspect where there can be N instances of the bis:ElementAspect class per bis:Element.
Base Class: BisCore:ElementAspect
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Element | The bis:Element that owns this bis:ElementMultiAspect. | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|
ElementUniqueAspect (Element Unique Aspect) Abstract EntityClass
A bis:ElementUniqueAspect is a bis:ElementAspect where there can be only zero or one instance of the bis:ElementAspect class per bis:Element.
Base Class: BisCore:ElementAspect
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Element | The bis:Element that owns this bis:ElementUniqueAspect | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|
EmbeddedFileLink (Embedded File Link) EntityClass
A bis:EmbeddedFileLink is a bis:LinkElement that links to a file embedded within the iModel.
Base Class: BisCore:LinkElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Name | A name for looking up the embedded file. Must be unique within the iModel. | string | |
| Description | A human-readable description of the Embedded File | string |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
ExternalSource (Source) EntityClass
An ExternalSource refers to an 'information container' found in a repository. In some cases, the container is the entire repository.
Base Class: BisCore:InformationReferenceElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Repository | The repository in which this 'information container' is stored. | navigation | |
| ConnectorName | Name of the iModel Connecter that processed this ExternalSource. | string | |
| ConnectorVersion | Version of the iModel Connecter that processed this ExternalSource. | string |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
ExternalSourceAspect (External Source Aspect) EntityClass
A bis:ElementMultiAspect that stores synchronization information for a bis:Element originating from an external source.
Base Class: BisCore:ElementMultiAspect
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Scope | The Id of a bis:Element that represents a scope in which the combination of properties 'Kind' and 'Identifier' will be unique. Used differently by different iModel Connectors. Recommended to point to a RepositoryLink when ids are unique per repository. | navigation | |
| Identifier | The identifier of the object in the source repository | string | |
| Kind | The kind of object within the source repository | string | |
| Version | An optional value that is typically a version number or a pseudo version number like last modified time. It will be used by the synchronization process to detect that a source object is unchanged so that computing a cryptographic hash can be avoided. If present, this value must be guaranteed to change when any of the source object's content changes. | string | |
| Checksum | The cryptographic hash (any algorithm) of the source object's content. If defined, it must be guaranteed to change when the source object's content changes. | string | |
| JsonProperties | A place where additional JSON properties can be stored. For example, provenance information or properties relating to the synchronization process. | string | Json |
| Source | The external source from which this element originated. | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Element | The bis:Element that owns this bis:ElementMultiAspect. | navigation |
ExternalSourceAttachment (External Source Attachment) EntityClass
Attachment of an ExternalSource
Base Class: BisCore:InformationReferenceElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Attaches | The ExternalSource that is attached by this ExternalSourceAttachment | navigation | |
| Role | If Role=SpecifyContext, the attached ExternalSource provides context. If Role=SpecifyPart, the attached ExternalSource models a part of the whole. | ExternalSourceAttachmentRole | |
| Translation | The translation or offset in global coordinates of the attached ExternalSource relative to the ExternalSource that attaches it. | point3d | |
| Yaw | The Yaw angle (in degrees) of the attached ExternalSource relative to the ExternalSource that attaches it. | double | |
| Pitch | The Pitch angle (in degrees) of the attached ExternalSource relative to the ExternalSource that attaches it. | double | |
| Roll | The Roll angle (in degrees) of the attached ExternalSource relative to the ExternalSource that attaches it. | double | |
| Scale | The scale of the attached ExternalSource relative to the ExternalSource that attaches it. | point3d |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
ExternalSourceGroup (External Source Group) EntityClass
A group of ExternalSources that are collectively a source of information for one or more elements.
Base Class: BisCore:ExternalSource
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Repository | The repository in which this 'information container' is stored. | navigation | |
| ConnectorName | Name of the iModel Connecter that processed this ExternalSource. | string | |
| ConnectorVersion | Version of the iModel Connecter that processed this ExternalSource. | string |
If the ExternalSourceGroup has a primary repository than it should be persisted in the Repository property from its base class.
If the group does not have a primary repository than that property should be left as NULL.
FolderLink (Folder Link) EntityClass
Represents a folder-like structure that organizes repositories (typically files) in an external system
Base Class: BisCore:UrlLink
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Url | A URL pointing to an external resource. | string | URI |
| Description | A human-readable description of the URL | string |
GeometricElement (Geometric Element) Abstract EntityClass
bis:GeometricElement is an abstract base class used to model real world Entities that intrinsically have geometry.
Base Class: BisCore:Element
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
GeometricElement2d (2D Geometric Element) Abstract EntityClass
bis:GeometricElement2d is an abstract base class used to model information Entities that intrinsically have 2D geometry.
Base Class: BisCore:GeometricElement
Behavior: The system handler (C++) for
GeometricElement2dwill only permit instances to be inserted into aGeometricModel2dand will require itsCategoryproperty to reference aDrawingCategory. The system handler also requires a valid placement ifGeometryStreamis notNULL.
See GeometryStream for a more in-depth explanation about that property.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Category | The bis:DrawingCategory used to categorize this bis:GeometricElement2d instance. | navigation | |
| Origin | The placement origin of this bis:Element. | point2d | |
| Rotation | The placement rotation (in degrees) of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point2d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point2d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than by instance of this Element. | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
GeometricElement3d (3D Geometric Element) Abstract EntityClass
bis:GeometricElement3d is an abstract base class used to model real world Entities that intrinsically have 3D geometry.
Base Class: BisCore:GeometricElement
Behavior: The system handler (C++) for
GeometricElement3dwill only permit instances to be inserted into aGeometricModel3dand will require itsCategoryproperty to reference aSpatialCategory. The system handler also requires a valid placement ifGeometryStreamis notNULL.
See GeometryStream for a more in-depth explanation about that property.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Category | The bis:SpatialCategory used to categorize this bis:GeometricElement3d | navigation | |
| InSpatialIndex | If true, this element will have an entry in the Spatial Index. | boolean | |
| Origin | The placement origin of this bis:Element. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this bis:Element. | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this bis:Element. | double | |
| Roll | The Roll angle (in degrees) of the orientation of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point3d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point3d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than per-instance of this Element. | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
GeometricModel (Geometric Model) Abstract EntityClass
A container for persisting bis:GeometricElement instances.
Base Class: BisCore:Model
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| GeometryGuid | A GUID that changes whenever any element in this GeometricModel has a change to its geometry. | binary | BeGuid |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime |
GeometricModel2d (2D Geometric Model) Abstract EntityClass
A container for persisting bis:GeometricElement2d instances.
Base Class: BisCore:GeometricModel
Behavior: The system handler (C++) for
GeometricModel2dwill preventGeometricElement3dinstances from being inserted to ensure that the model will only contain 2d geometry. This restriction applies to allGeometricModel2dsubclasses.InformationContentElementinstances (other thanDefinitionElementsubclasses) can also be inserted into aGeometricModel2d.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| GlobalOrigin | The actual coordinates of (0,0) in modeling coordinates. An offset applied to all modeling coordinates. | point2d |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime | |
| GeometryGuid | A GUID that changes whenever any element in this GeometricModel has a change to its geometry. | binary | BeGuid |
GeometricModel3d (3D Geometric Model) Abstract EntityClass
A container for persisting bis:GeometricElement3d instances, which are considered to be in the iModel's real-world coordinate system unless their InSpatialIndex property has been set to 'false'.
Base Class: BisCore:GeometricModel
Behavior: The system handler (C++) for
GeometricModel3dwill preventGeometricElement2dinstances from being inserted to ensure that the model will only contain 3d geometry. This restriction applies to allGeometricModel3dsubclasses.InformationContentElementinstances (other thanDefinitionElementsubclasses) can also be inserted into aGeometricModel3d.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| IsNotSpatiallyLocated | If IsNotSpatiallyLocated is true, then the elements in this bis:GeometricModel3d are not in real-world coordinates and will not be in the spatial index. | boolean | |
| IsPlanProjection | If IsPlanProjection is true, then the elements in this bis:GeometricModel3d are expected to be in an XY plane. | boolean |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime | |
| GeometryGuid | A GUID that changes whenever any element in this GeometricModel has a change to its geometry. | binary | BeGuid |
GeometryPart (Geometry Part) EntityClass
A bis:DefinitionElement that specifies a collection of geometry that is meant to be reused across bis:GeometricElement instances. Leveraging bis:GeometryParts can help reduce file size and improve display performance.
Base Class: BisCore:DefinitionElement
Behavior: The system handler (C++) for
GeometryPartrequires valid geometry stored in theGeometryStreamproperty for insertion to succeed. The system handler also restricts deletion. AGeometryPartcan only be deleted via a more expensivedeleteDefinitionElementsmethod that has determined theGeometryPartis no longer referenced.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| GeometryStream | The actual geometry of the Geometry Part | binary | GeometryStream |
| BBoxLow | The low corner of the Geometry Part's bounding box. | point3d | |
| BBoxHigh | The high corner of the Geometry Part's bounding box | point3d |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
GraphicalElement2d (2D Graphical Element) Abstract EntityClass
bis:GraphicalElement2d is an abstract base class for 2D geometric elements that are used to convey information within graphical presentations (like drawings).
Base Class: BisCore:GeometricElement2d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:DrawingCategory used to categorize this bis:GeometricElement2d instance. | navigation | |
| Origin | The placement origin of this bis:Element. | point2d | |
| Rotation | The placement rotation (in degrees) of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point2d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point2d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than by instance of this Element. | navigation |
GraphicalElement3d (3D Graphical Element) Abstract EntityClass
A bis:GraphicalElement3d element conveys information within 3D graphical presentations.
Base Class: BisCore:GeometricElement3d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:SpatialCategory used to categorize this bis:GeometricElement3d | navigation | |
| InSpatialIndex | If true, this element will have an entry in the Spatial Index. | boolean | |
| Origin | The placement origin of this bis:Element. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this bis:Element. | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this bis:Element. | double | |
| Roll | The Roll angle (in degrees) of the orientation of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point3d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point3d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than per-instance of this Element. | navigation |
GraphicalModel2d (2D Graphical Model) Abstract EntityClass
A container for persisting bis:GraphicalElement2d instances.
Base Class: BisCore:GeometricModel2d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime | |
| GeometryGuid | A GUID that changes whenever any element in this GeometricModel has a change to its geometry. | binary | BeGuid |
| GlobalOrigin | The actual coordinates of (0,0) in modeling coordinates. An offset applied to all modeling coordinates. | point2d |
GraphicalModel3d (3D Graphical Model) Abstract EntityClass
A container for persisting bis:GraphicalElement3d instances.
Base Class: BisCore:GeometricModel3d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime | |
| GeometryGuid | A GUID that changes whenever any element in this GeometricModel has a change to its geometry. | binary | BeGuid |
| IsNotSpatiallyLocated | If IsNotSpatiallyLocated is true, then the elements in this bis:GeometricModel3d are not in real-world coordinates and will not be in the spatial index. | boolean | |
| IsPlanProjection | If IsPlanProjection is true, then the elements in this bis:GeometricModel3d are expected to be in an XY plane. | boolean |
GraphicalPartition3d (3D Graphical Partition) Sealed EntityClass
A bis:GraphicalPartition3d element establishes a '3D Graphical' Modeling Perspective for its parent bis:Subject. A bis:GraphicalPartition3d is always sub-modeled by a bis:GraphicalModel3d.
Base Class: BisCore:InformationPartitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Description | A human-readable string describing the intent behind the partition. | string |
GraphicalType2d (2D Graphical Type) Abstract EntityClass
Defines a shared set of properties (the 'type') that can be associated with a bis:GraphicalElement2d instance.
Base Class: BisCore:TypeDefinitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Recipe | navigation |
GroupInformationElement (Group Information) Abstract EntityClass
bis:GroupInformationElement is an abstract base class used for modeling Entities whose main purpose is to group related elements.
Base Class: BisCore:InformationReferenceElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
GroupInformationModel (Group Information Model) Abstract EntityClass
A container for persisting bis:GroupInformationElement instances.
Base Class: BisCore:InformationModel
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime |
Behavior: The system handler (C++) for
GroupInformationModelwill only permit the insertion ofGroupInformationElementinstances. The modeled element for anGroupInformationModelis expected to be anGroupInformationPartition.
GroupInformationPartition (Group Information Partition) Sealed EntityClass
A bis:GroupInformationPartition element establishes a 'Group Information' Modeling Perspective for its parent bis:Subject. A bis:GroupInformationPartition is always sub-modeled by a bis:GroupInformationModel.
Base Class: BisCore:InformationPartitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Description | A human-readable string describing the intent behind the partition. | string |
The 'GroupInformation' Modeling Perspective is a subset of the 'Information' Modeling Perspective. It is used primarily to hold generic:Group Elements generated from DgnV8 'Named Groups'.
Behavior: The system handler (C++) for
GroupInformationPartitionensures that it is only ever sub-modeled by aGroupInformationModel.
InformationCarrierElement (Information Carrier) Abstract EntityClass Deprecated
DEPRECATED: An Information Carrier carries information, but is not the information itself. For example, the arrangement of ink on paper or the sequence of electronic bits are information carriers.
Base Class: BisCore:Element
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
InformationContentElement (Information Content Element) Abstract EntityClass
bis:InformationContentElement is an abstract base class for modeling pure information Entities. Only the core framework should directly subclass from bis:InformationContentElement. Domain and application developers should start with the most appropriate subclass of bis:InformationContentElement.
Base Class: BisCore:Element
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
InformationModel (Information Model) Abstract EntityClass
A container for persisting bis:InformationContentElement instances.
Base Class: BisCore:Model
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime |
Behavior: The system handler (C++) for
InformationModelwill only permit the insertion ofInformationContentElementinstances. This restriction applies to allInformationModelsubclasses.
InformationPartitionElement (Information Partition) Abstract EntityClass
An instance of a specialization of bis:InformationPartitionElement establishes a particular Modeling Perspective for its parent bis:Subject. Instances are always sub-modeled by a specialization of bis:Model of the appropriate Modeling Perspective.
Base Class: BisCore:InformationContentElement
An InformationPartitionElement partitions the information in a BIS Repository into non-overlapping hierarchies of Models and Elements, each with a distinct Modeling Perspective. In some cases it further-partitions information into distinct subsets within a Modeling Perspective, based on a specific domain.
A bis:Subject mentions a real-world Object. BIS sees the Object as one-or-more Entities, where each Entity considers the Object from a particular Modeling Perspective. A specialization of a bis:InformationPartitionElement establishes a Perspective for modeling the Object to which the Subject refers. The top-Model sub-models the Partition. The actual modeling of the Entity with one-or-more Elements of the appropriate Modeling Perspective begins in the top-Model.
See Top of the World
Behavior: The system handler (C++) for
InformationPartitionElementwill only permit instances to be inserted into theRepositoryModel. The system handler will also require everyInformationPartitionElementto have itsParentproperty reference aSubject.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Description | A human-readable string describing the intent behind the partition. | string |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
InformationRecordElement (Information Record Element) Abstract EntityClass
bis:InformationRecordElement is an abstract base class for modeling information records. The bis:InformationRecordElement class is the default choice if no other subclass of bis:InformationContentElement makes sense.
Base Class: BisCore:InformationContentElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
InformationRecordModel (Information Record Model) EntityClass
A container for persisting bis:InformationRecordElement instances
Base Class: BisCore:InformationModel
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime |
Behavior: The system handler (C++) for
InformationRecordModelwill only permit the insertion ofInformationRecordElementinstances. The modeled element for anInformationRecordModelis expected to be anInformationRecordPartition.
InformationRecordPartition (Information Record Partition) Sealed EntityClass
A bis:InformationRecordPartition element establishes a 'Information Record' Modeling Perspective for its parent bis:Subject. A bis:InformationRecordPartition is always sub-modeled by a bis:InformationRecordModel.
Base Class: BisCore:InformationPartitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Description | A human-readable string describing the intent behind the partition. | string |
The 'InformationRecord' Modeling Perspective is a subset of the 'Information' Modeling Perspective. It can hold a broad array of information records describing Entities.
Behavior: The system handler (C++) for
InformationRecordPartitionensures that it is only ever sub-modeled by aInformationRecordModel.
InformationReferenceElement (Information Reference) Abstract EntityClass
bis:InformationReferenceElement is an abstract base class used for modeling Entities whose main purpose is to reference something else.
Base Class: BisCore:InformationContentElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
LightLocation (Light Location) Sealed EntityClass
The spatial location of a light source
Base Class: BisCore:SpatialLocationElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Enabled | Indicates that the light is on. | boolean |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:SpatialCategory used to categorize this bis:GeometricElement3d | navigation | |
| InSpatialIndex | If true, this element will have an entry in the Spatial Index. | boolean | |
| Origin | The placement origin of this bis:Element. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this bis:Element. | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this bis:Element. | double | |
| Roll | The Roll angle (in degrees) of the orientation of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point3d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point3d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than per-instance of this Element. | navigation |
LineStyle (Line Style) Sealed EntityClass
Base Class: BisCore:DefinitionElement
Behavior: The system handler restricts deletion. A
LineStylecan only be deleted via a more expensivedeleteDefinitionElementsmethod that has determined theLineStyleis no longer referenced.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Description | Description of the style | string | |
| Data | Encoded style properties | string | Json |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
LinkElement (Link) Abstract EntityClass
A bis:LinkElement is a bis:InformationReferenceElement that specifies a link to some resource that is not modeled with BIS.
Base Class: BisCore:InformationReferenceElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
The link is generally to some resource, e.g. the subclass UrlLink points to an external resource while EmbeddedFileLink points to files embedded in an iModel.
Behavior: The system handler (C++) for
LinkElementensures that it is only ever inserted into anInformationModel.
LinkModel (Link Model) EntityClass
A container for persisting bis:LinkElement instances.
Base Class: BisCore:InformationModel
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime |
Behavior: The system handler (C++) for
LinkModelwill only permit the insertion ofLinkElementinstances. The modeled element for anLinkModelis expected to be aLinkPartition.
LinkPartition (Link Partition) Sealed EntityClass
A bis:LinkPartition element establishes a 'Link' Modeling Perspective for its parent bis:Subject. A bis:LinkPartition is always sub-modeled by a bis:LinkModel.
Base Class: BisCore:InformationPartitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Description | A human-readable string describing the intent behind the partition. | string |
The 'Link' Modeling Perspective is a subset of the 'Information' Modeling Perspective. It is used to hold links to external repositories, e.g. in the form of bis:RepositoryLink elements.
Behavior: The system handler (C++) for
LinkPartitionensures that it is only ever sub-modeled by aLinkModel.
Model Abstract EntityClass
A bis:Model is a container for persisting a collection of related elements.
See Model Fundamentals.
Behavior: System handlers (written in C++) and domain handlers (written in TypeScript) provide behavior to specific
Modelsubclasses. The system handler forModelrequires itsModeledElementproperty to reference anElementthat implementsISubModeledElement. This is enforced for allModelsubclasses.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime |
ModelSelector (Model Selector) EntityClass
Specifies the list of 3d models displayed by a SpatialViewDefinition. Multiple SpatialViewDefinitions may point to the same ModelSelector.
Base Class: BisCore:DefinitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
Behavior: The system handler restricts deletion. A
ModelSelectorcan only be deleted via a more expensivedeleteDefinitionElementsmethod that has determined theModelSelectoris no longer referenced.
OrthographicViewDefinition (Orthographic Spatial View) EntityClass
A spatial view that always shows a parallel projection.
Base Class: BisCore:SpatialViewDefinition
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Description | A human-readable description of the View Definition | string | |
| CategorySelector | navigation | ||
| DisplayStyle | navigation | ||
| Origin | Origin of the viewed volume on the lower, back, rear | point3d | |
| Extents | Size of the view diagonal | point3d | |
| Yaw | Yaw component of the view direction in degrees | double | |
| Pitch | Pitch component of the view direction in degrees | double | |
| Roll | Roll component of the view direction in degrees | double | |
| IsCameraOn | Is the camera actually turned on? | boolean | |
| EyePoint | Camera eye point | point3d | |
| LensAngle | Camera lens angle in degrees | double | |
| FocusDistance | Camera focus distance | double | |
| ModelSelector | navigation |
PhysicalElement (Physical Element) Abstract EntityClass
A bis:PhysicalElement is spatially located, has mass, and can be 'touched'.
Base Class: BisCore:SpatialElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| PhysicalMaterial | Indicates the bis:PhysicalMaterial of which the bis:PhysicalElement is made. | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:SpatialCategory used to categorize this bis:GeometricElement3d | navigation | |
| InSpatialIndex | If true, this element will have an entry in the Spatial Index. | boolean | |
| Origin | The placement origin of this bis:Element. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this bis:Element. | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this bis:Element. | double | |
| Roll | The Roll angle (in degrees) of the orientation of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point3d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point3d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than per-instance of this Element. | navigation |
PhysicalMaterial (Physical Material) Abstract EntityClass
A bis:PhysicalMaterial defines the matter of which physical objects are made. bis:PhysicalMaterials are not used to define rendering characteristics (see bis:RenderMaterial).
Base Class: BisCore:DefinitionElement
The PhysicalMaterial serves as the base class for the materials in the PhysicalMaterial schema. Generally, it is expected that domain-specific properties (e.g. strength properties for the structural domain) will be added to the subclasses such as Concrete and Steel using domain-specific ElementAspects.
The Density property in this base PhysicalMaterial class is intended to provide basic weight computation for the purposes of quantity takeoff and carbon footprint, for example, which are cross-domain functions. This kindOfQuantity for this property is AECU:DENSITY.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Density | double |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
PhysicalModel (Physical Model) EntityClass
A container for persisting bis:PhysicalElement and bis:SpatialLocationElement instances used to model real physical space. Also allows bis:GraphicalElement3d and bis:InformationContentElement.
Base Class: BisCore:SpatialModel
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime | |
| GeometryGuid | A GUID that changes whenever any element in this GeometricModel has a change to its geometry. | binary | BeGuid |
| IsNotSpatiallyLocated | If IsNotSpatiallyLocated is true, then the elements in this bis:GeometricModel3d are not in real-world coordinates and will not be in the spatial index. | boolean | |
| IsPlanProjection | If IsPlanProjection is true, then the elements in this bis:GeometricModel3d are expected to be in an XY plane. | boolean |
PhysicalPartition (Physical Partition) Sealed EntityClass
A bis:PhysicalPartition element establishes a 'Physical' Modeling Perspective for its parent bis:Subject. A bis:PhysicalPartition is always sub-modeled by a bis:PhysicalModel.
Base Class: BisCore:InformationPartitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Description | A human-readable string describing the intent behind the partition. | string |
The 'Physical' Perspective is for modeling physical Entities (which have mass) and for spatial location Entities (which are generally either defined-by physical Entities or are used-to-define physical Entities).
Behavior: The system handler (C++) for
PhysicalPartitionensures that it is only ever sub-modeled by aSpatialModel.
PhysicalPortion (Physical Portion) Abstract EntityClass Deprecated
DEPRECATED: A Physical Portion represents an arbitrary portion of a larger Physical Element that will be sub-modeled by a Physical Model.
Base Class: BisCore:PhysicalElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:SpatialCategory used to categorize this bis:GeometricElement3d | navigation | |
| InSpatialIndex | If true, this element will have an entry in the Spatial Index. | boolean | |
| Origin | The placement origin of this bis:Element. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this bis:Element. | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this bis:Element. | double | |
| Roll | The Roll angle (in degrees) of the orientation of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point3d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point3d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than per-instance of this Element. | navigation | |
| PhysicalMaterial | Indicates the bis:PhysicalMaterial of which the bis:PhysicalElement is made. | navigation |
PhysicalSystem (Physical System) Abstract EntityClass
A collection of connected SpatialElements (primarily PhysicalElements) that collectively implement some function.
Base Class: BisCore:GroupInformationElement
A non-exclusive set of SpatialElements grouped using the PhysicalSystemGroupsMembers relationship. A SpatialElement can be a member of multiple PhysicalSystems.
The primary contents of the PhysicalSystem are PhysicalElements, but SpatialLocationElements can be included, as well.
The hierarchy of PhysicalSystems is built using the PhysicalSystemAggregatesSubSystems relationship, similar to IfcRelAggregates. The "source" Element of the relationship is an "Aggregator" that aggregates parts that are essentially a different representation of the aggregator, but at a finer granularity.
A Physical System can define as many levels of hierarchy as needed.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| AggregatingSystem | The aggregator of this sub-system within the System hierarchy. | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
PhysicalSystemModel (Physical System Model) EntityClass
A container for persisting bis:PhysicalSystem elements.
Base Class: BisCore:InformationModel
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime |
PhysicalSystemPartition (Physical System Partition) Sealed EntityClass
A bis:PhysicalSystemPartition element establishes a 'Physical System' Modeling Perspective for its parent bis:Subject. A bis:PhysicalSystemPartition is always sub-modeled by a bis:PhysicalSystemModel.
Base Class: BisCore:InformationPartitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Description | A human-readable string describing the intent behind the partition. | string |
The 'Physical System' Modeling Perspective is a subset of the 'Information' Modeling Perspective. It holds Elements which group a collection of connected Entities (primarily Physical) that collectively implement some function..
PhysicalType (Physical Type) Abstract EntityClass
Defines a shared set of properties whose values vary per-type of a bis:PhysicalElement rather than per-instance. Intended for modeling Entities such as catalog entries, that typically define property values that are common among all instances associated with a given catalog entry.
Base Class: BisCore:TypeDefinitionElement
A PhysicalType is particularly useful in cases where a physical item can be ordered from a catalog.
Each type of item will have the same set of type-specific properties.
For example: manufacturer name, model number, maintenance intervals, etc.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| PhysicalMaterial | Indicates the bis:PhysicalMaterial of which bis:PhysicalElements of the given bis:PhysicalType are made. | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Recipe | navigation |
RecipeDefinitionElement (Recipe Definition) Abstract EntityClass
Defines instructions for creating/updating Element instances, e.g. determining their geometry from a template or a parametric script.
Base Class: BisCore:DefinitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
RenderMaterial (Render Material) Sealed EntityClass
A bis:RenderMaterial defines the rendering properties of materials for display. Not to be confused with a bis:PhysicalMaterial.
Base Class: BisCore:DefinitionElement
Marked as "Sealed" because JsonProperties will be used to persist data. This allows a single instance to "morph" between a DgnV8 render material and a future PBR material.
Behavior: The system handler restricts deletion. A
RenderMaterialcan only be deleted via a more expensivedeleteDefinitionElementsmethod that has determined theRenderMaterialis no longer referenced.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| PaletteName | The palette name that categorizes this RenderMaterial. | string | |
| Description | A human-readable description of the RenderMaterial | string |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
RenderTimeline (Render Timeline) EntityClass
Timeline information for rendering and visualizing animations and schedule simulations.
Base Class: BisCore:InformationRecordElement
This information used to be stored within the DisplayStyle but was refactored out as a separate element for efficiency and reuse purposes.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Description | An optional, human-readable description of the Render Timeline | string | |
| Script | A JSON string containing the timeline and rendering instructions | string | Json |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
RepositoryLink (Repository Link) EntityClass
A bis:RepositoryLink is a bis:UrlLink element that links to an external repository. It implements ISubModeledElement only so that a sub-Model could be used to cache information from the external repository.
Base Class: BisCore:UrlLink
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| RepositoryGuid | A GUID that identifies the external repository. | binary | BeGuid |
| Format | The format of the external repository. | string |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Url | A URL pointing to an external resource. | string | URI |
| Description | A human-readable description of the URL | string |
RepositoryModel (Repository Model) Sealed EntityClass
The singleton Model at the root of a BIS repository. Contains a hierarchy of bis:Subject elements that declare what the repository is modeling and child bis:InformationPartitionElement instances that establish Modeling Perspectives. Serves as a high-level table-of-contents for the BIS repository.
Base Class: BisCore:DefinitionModel
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime |
Behavior: The singleton
RepositoryModelbehaves like a standardInformationModeland should have been a direct subclass ofInformationModel. Unfortunately, it subclasses fromDefinitionModelfor legacy reasons that are no longer relevant. However, the system handler (C++) forRepositoryModelmakes it act like a direct subclass ofInformationModel. Consistent with a standardInformationModel, allInformationContentElementinstances exceptDefinitionElementsubclasses may be inserted. For backwards compatibility reasons, the superclass ofRepositoryModelcannot be corrected until a major schema version upgrade.
RoleElement (Role Element) Abstract EntityClass
A real world Entity is modeled as a bis:RoleElement when a set of external circumstances define an important role (one that is worth tracking) that is not intrinsic to the Entity playing the role. For example, a person can play the role of a teacher or a rock can play the role of a boundary marker.
Base Class: BisCore:Element
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
An Entity is modeled as a bis:RoleElement when a set of external circumstances define an important role (one that is worth tracking) that is not intrinsic to the Entity playing the role. For example, a person can play the role of a teacher or a rock can play the role of a boundary marker.
Behavior: The system handler (C++) for
RoleElementwill only permit instances to be inserted into aRoleModel. This behavior applies to allRoleElementsubclasses.FunctionalElement(from theFunctionalschema) is the most widely known subclass ofRoleElement.
RoleModel (Role Model) EntityClass
A container for persisting bis:RoleElement instances. This class should be considered abstract, so the appropriate subclass of bis:RoleModel should be used instead.
Base Class: BisCore:Model
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime |
Behavior: The system handler (C++) for
RoleModelpreventsGeometricElementinstances from being inserted since the primary intent is for aRoleModelto containRoleElementinstances.InformationContentElementinstances (other thanDefinitionElementsubclasses) can also be inserted into aRoleModel. This behavior applies to allRoleModelsubclasses.FunctionalModel(from theFunctionalschema) is the most widely known subclass ofRoleModel.
SectionDrawing (Section Drawing) EntityClass
A bis:SectionDrawing is a bis:Drawing of a 2D section of a spatial view. A bis:SectionDrawing can be sub-modeled by a DrawingModel or a GraphicalModel3d.
Base Class: BisCore:Drawing
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| SectionType | Type of the section: e.g. Section, Plan, Elevation, Detail. | SectionType | |
| SpatialView | The SpatialViewDefinition used to generate this SectionDrawing. | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
SectionDrawingLocation (Section Drawing Location) EntityClass
The spatial location of a section drawing generated from a SpatialViewDefinition.
Base Class: BisCore:SpatialLocationElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| SectionView | The section view generated from the SpatialViewDefinition. | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:SpatialCategory used to categorize this bis:GeometricElement3d | navigation | |
| InSpatialIndex | If true, this element will have an entry in the Spatial Index. | boolean | |
| Origin | The placement origin of this bis:Element. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this bis:Element. | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this bis:Element. | double | |
| Roll | The Roll angle (in degrees) of the orientation of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point3d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point3d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than per-instance of this Element. | navigation |
SectionDrawingModel (Section Drawing Model) EntityClass
A container for persisting section bis:DrawingGraphic elements representing a cross-section of a PhysicalModel. Generally at the same scale as the sectioned geometry to allow it to be display in situ at the location of the sectioning.
Base Class: BisCore:DrawingModel
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime | |
| GeometryGuid | A GUID that changes whenever any element in this GeometricModel has a change to its geometry. | binary | BeGuid |
| GlobalOrigin | The actual coordinates of (0,0) in modeling coordinates. An offset applied to all modeling coordinates. | point2d |
SectionLocation (Section Location) EntityClass Deprecated
DEPRECATED: The section location defines how a section drawing should be generated in a 3d view.
Base Class: BisCore:SpatialLocationElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| SectionType | Type of the section: e.g. Section, Plan, Elevation, Detail. | SectionType | |
| ClipGeometry | Details on how this section was clipped. | string | Json |
| ModelSelector | Describes the models relevant for this section location display. | navigation | |
| CategorySelector | Describes the categories relevant for this section location display. | navigation | |
| ViewAttachment | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:SpatialCategory used to categorize this bis:GeometricElement3d | navigation | |
| InSpatialIndex | If true, this element will have an entry in the Spatial Index. | boolean | |
| Origin | The placement origin of this bis:Element. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this bis:Element. | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this bis:Element. | double | |
| Roll | The Roll angle (in degrees) of the orientation of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point3d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point3d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than per-instance of this Element. | navigation |
Sheet EntityClass
A bis:Sheet is a bis:Document of a 2D sheet.
Base Class: BisCore:Document
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Scale | The Sheet's drawing scale | double | |
| Height | Height of the Sheet (in meters) | double | |
| Width | Width of the Sheet (in meters) | double | |
| SheetTemplate | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
SheetBorder (Sheet Border) EntityClass
Base Class: BisCore:DrawingGraphic
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| BorderTemplate | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:DrawingCategory used to categorize this bis:GeometricElement2d instance. | navigation | |
| Origin | The placement origin of this bis:Element. | point2d | |
| Rotation | The placement rotation (in degrees) of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point2d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point2d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than by instance of this Element. | navigation |
SheetBorderTemplate (Sheet Border Template) EntityClass
Base Class: BisCore:Document
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Height | Height of the sheet border. | double | |
| Width | Width of the sheet border. | double |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
SheetIndex EntityClass
A bis:InformationReferenceElement used to organize bis:Sheet instances into a hierarchy with the assistance of bis:SheetIndexFolder and other bis:SheetIndex instances.
Base Class: BisCore:InformationReferenceElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
Instances of SheetIndex are always contained within a SheetIndexModel.
SheetIndexEntry Abstract EntityClass
A bis:InformationReferenceElement used as the base-class for elements that participate in a Sheet-Index hierarchy.
Base Class: BisCore:InformationReferenceElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| EntryPriority | Can be used to prioritize or order members within a SheetIndex or SheetIndexFolder. | int |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
SheetIndexFolder EntityClass
A SheetIndexEntry used to organize other SheetIndexEntry instances in a hierarchy.
Base Class: BisCore:SheetIndexEntry
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| EntryPriority | Can be used to prioritize or order members within a SheetIndex or SheetIndexFolder. | int |
Instances of SheetIndexFolder are always contained within a SheetIndexModel.
SheetIndexModel (Sheet Index Model) EntityClass
A container for persisting bis:SheetIndexEntry and bis:SheetIndex elements.
Base Class: BisCore:InformationModel
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime |
SheetIndexPartition (Sheet Index Partition) Sealed EntityClass
A bis:SheetIndexPartition element establishes a 'Sheet Index' Modeling Perspective for its parent bis:Subject. A bis:SheetIndexPartition is always sub-modeled by a bis:SheetIndexModel.
Base Class: BisCore:InformationPartitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Description | A human-readable string describing the intent behind the partition. | string |
The 'Sheet Index' Modeling Perspective is a subset of the 'Information' Modeling Perspective. It holds Elements that organize Sheets into hierarchies for easier access.
SheetIndexReference EntityClass
A SheetIndexEntry used to include a SheetIndex hierarchy into another one.
Base Class: BisCore:SheetIndexEntry
Instances of SheetIndexReference are always contained within a SheetIndexModel.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| SheetIndex | The bis:SheetIndex that this bis:SheetIndexReference is ponting to. | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| EntryPriority | Can be used to prioritize or order members within a SheetIndex or SheetIndexFolder. | int |
SheetModel (Sheet Model) EntityClass
A container for persisting sheet views and graphics.
Base Class: BisCore:GraphicalModel2d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime | |
| GeometryGuid | A GUID that changes whenever any element in this GeometricModel has a change to its geometry. | binary | BeGuid |
| GlobalOrigin | The actual coordinates of (0,0) in modeling coordinates. An offset applied to all modeling coordinates. | point2d |
SheetReference EntityClass
A SheetIndexEntry used to include a Sheet instance into a Sheet-Index hierarchy.
Base Class: BisCore:SheetIndexEntry
Instances of SheetReference are always contained within a SheetIndexModel.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Sheet | The bis:Sheet that this bis:SheetReference is ponting to. | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| EntryPriority | Can be used to prioritize or order members within a SheetIndex or SheetIndexFolder. | int |
SheetTemplate (Sheet Template) EntityClass
Base Class: BisCore:Document
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Height | Height of the sheet. | double | |
| Width | Width of the sheet. | double | |
| Border | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
SheetViewDefinition (Sheet View Definition) EntityClass
A bis:SheetViewDefinition specifies parameters for a view of a bis:SheetModel.
Base Class: BisCore:ViewDefinition2d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Description | A human-readable description of the View Definition | string | |
| CategorySelector | navigation | ||
| DisplayStyle | navigation | ||
| BaseModel | navigation | ||
| Origin | Lower left corner of the viewed area. | point2d | |
| Extents | Size of the view diagonal | point2d | |
| RotationAngle | Rotation angle in degrees of the viewed area. | double |
SpatialCategory (Spatial Category) Sealed EntityClass
A bis:SpatialCategory is used for classifying bis:GeometricElement3d elements via the bis:GeometricElement3dIsInCategory (concrete and sealed) relationship.
Base Class: BisCore:Category
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Description | A human-readable description of the Category | string | |
| Rank | The Rank of a category indicates how it was created and where it can be used. 0=System; 1=Domain; 2=Application; 3=User. | int |
SpatialElement (Spatial Element) Abstract EntityClass
A bis:SpatialElement is a bis:GeometricElement3d that occupies real world space.
Base Class: BisCore:GeometricElement3d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:SpatialCategory used to categorize this bis:GeometricElement3d | navigation | |
| InSpatialIndex | If true, this element will have an entry in the Spatial Index. | boolean | |
| Origin | The placement origin of this bis:Element. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this bis:Element. | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this bis:Element. | double | |
| Roll | The Roll angle (in degrees) of the orientation of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point3d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point3d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than per-instance of this Element. | navigation |
SpatialIndex (Spatial Index) Sealed EntityClass
The Spatial Index contains information used to optimize spatial queries. Like other database indices, it is automatically maintained by the system.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| MinX | Minimum X value of the axis-aligned range box that encloses the spatial element | double | |
| MaxX | Maximum X value of the axis-aligned range box that encloses the spatial element | double | |
| MinY | Minimum Y value of the axis-aligned range box that encloses the spatial element | double | |
| MaxY | Maximum Y value of the axis-aligned range box that encloses the spatial element | double | |
| MinZ | Minimum Z value of the axis-aligned range box that encloses the spatial element | double | |
| MaxZ | Maximum Z value of the axis-aligned range box that encloses the spatial element | double |
SpatialLocationElement (Spatial Location Element) Abstract EntityClass
A bis:SpatialLocationElement identifies a 'tracked' real world location but has no mass and cannot be 'touched'.
Base Class: BisCore:SpatialElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:SpatialCategory used to categorize this bis:GeometricElement3d | navigation | |
| InSpatialIndex | If true, this element will have an entry in the Spatial Index. | boolean | |
| Origin | The placement origin of this bis:Element. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this bis:Element. | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this bis:Element. | double | |
| Roll | The Roll angle (in degrees) of the orientation of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point3d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point3d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than per-instance of this Element. | navigation |
SpatialLocationModel (Spatial Location Model) EntityClass
A container for persisting bis:SpatialLocationElement instances. Also allows bis:GraphicalElement3d and bis:InformationContentElement.
Base Class: BisCore:SpatialModel
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime | |
| GeometryGuid | A GUID that changes whenever any element in this GeometricModel has a change to its geometry. | binary | BeGuid |
| IsNotSpatiallyLocated | If IsNotSpatiallyLocated is true, then the elements in this bis:GeometricModel3d are not in real-world coordinates and will not be in the spatial index. | boolean | |
| IsPlanProjection | If IsPlanProjection is true, then the elements in this bis:GeometricModel3d are expected to be in an XY plane. | boolean |
Behavior: The system handler (C++) for
SpatialLocationModelwill preventPhysicalElementinstances from being inserted since the primary intent is for the model to containSpatialLocationElementinstances.InformationContentElementinstances (other thanDefinitionElementsubclasses) can also be inserted into aSpatialLocationModel. The restrictions from theGeometricModel3dsuperclass also apply.
SpatialLocationPartition (Spatial Location Partition) Sealed EntityClass
A bis:SpatialLocationPartition element establishes a 'SpatialLocation' Modeling Perspective for its parent bis:Subject. A bis:SpatialLocationPartition is always sub-modeled by a bis:SpatialLocationModel.
Base Class: BisCore:InformationPartitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Description | A human-readable string describing the intent behind the partition. | string |
The “Spatial Location” perspective is a strict subset of the “Physical” perspective. Spatial locations are massless, but they manifest in the real physical world:
- They may be defined in relation to physical entities, e.g. the air gap between two conductors, the space around an access panel, the volume occupied by a physical Entity, or a surface demarcating a region on the surface of a physical entity.
- They may be used to guide positioning of physical Entities, e.g. grid lines that may be manifested physically on a construction site via chalk lines or laser beams.
- They may be abstractions of physical consequence, like property or political boundaries that are often demarcated in the physical world via markers, signs, or natural boundaries.
The 'Spatial Location' perspective is used by SpatialLocationModel and SpatialLocationElement in order to segregate certain kinds of elements.
In retrospect, the complexity added by introducing a distinct "Spatial Location" perspective may have not been worth the benefit. Our current recommendation is to not instantiate a SpatialLocationPartition, but instead organize spatial locations in the context of the 'physical backbone', i.e. the Physical model hierarchy.
Behavior: The system handler (C++) for
SpatialLocationPartitionensures that it is only ever sub-modeled by aSpatialLocationModel.
SpatialLocationPortion (Spatial Location Portion) Abstract EntityClass Deprecated
DEPRECATED: A Spatial Location Portion represents an arbitrary portion of a larger Spatial Location Element that will be sub-modeled by a Spatial Location Model.
Base Class: BisCore:SpatialLocationElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:SpatialCategory used to categorize this bis:GeometricElement3d | navigation | |
| InSpatialIndex | If true, this element will have an entry in the Spatial Index. | boolean | |
| Origin | The placement origin of this bis:Element. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this bis:Element. | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this bis:Element. | double | |
| Roll | The Roll angle (in degrees) of the orientation of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point3d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point3d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than per-instance of this Element. | navigation |
SpatialLocationType (Spatial Location Type) Abstract EntityClass
Defines a shared set of properties whose values vary per-type of a bis:SpatialLocationElement rather than per-instance.
Base Class: BisCore:TypeDefinitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Recipe | navigation |
SpatialModel (Spatial Model) Abstract EntityClass
An abstract base class for bis:PhysicalModel and bis:SpatialLocationModel--the only two types of model for real physical space. Other GeometricModel3d specializations use the real-world coordinate system, but are considered as informational or mathematical abstractions.
Base Class: BisCore:GeometricModel3d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime | |
| GeometryGuid | A GUID that changes whenever any element in this GeometricModel has a change to its geometry. | binary | BeGuid |
| IsNotSpatiallyLocated | If IsNotSpatiallyLocated is true, then the elements in this bis:GeometricModel3d are not in real-world coordinates and will not be in the spatial index. | boolean | |
| IsPlanProjection | If IsPlanProjection is true, then the elements in this bis:GeometricModel3d are expected to be in an XY plane. | boolean |
SpatialViewDefinition (Spatial View Definition) EntityClass
A view of a spatially located volume.
Base Class: BisCore:ViewDefinition3d
Behavior: The system handler (C++) for
SpatialViewDefinitionrequires a validModelSelectorreference. The restrictions of the superclass also apply.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ModelSelector | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Description | A human-readable description of the View Definition | string | |
| CategorySelector | navigation | ||
| DisplayStyle | navigation | ||
| Origin | Origin of the viewed volume on the lower, back, rear | point3d | |
| Extents | Size of the view diagonal | point3d | |
| Yaw | Yaw component of the view direction in degrees | double | |
| Pitch | Pitch component of the view direction in degrees | double | |
| Roll | Roll component of the view direction in degrees | double | |
| IsCameraOn | Is the camera actually turned on? | boolean | |
| EyePoint | Camera eye point | point3d | |
| LensAngle | Camera lens angle in degrees | double | |
| FocusDistance | Camera focus distance | double |
SubCategory (Sub-Category) Sealed EntityClass
A bis:SubCategory is a subdivision of a bis:Category. SubCategories allow GeometricElements to have multiple pieces of Geometry that can be independently visible and styled (color, linesStyle, transparency, etc.). It is important to understand that a bis:SubCategory is not a bis:Category (i.e. Categories do not nest). bis:GeometricElements are always related to a bis:Category, not a bis:SubCategory.
Base Class: BisCore:DefinitionElement
Behavior: The system handler (C++) for
SubCategoryrequires a validCodeValue(name) and aParentproperty that references its owningCategory. The system handler also restricts deletion. ASubCategorycan only be deleted via a more expensivedeleteDefinitionElementsmethod that has determined theSubCategoryis no longer referenced.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Description | A human-readable description of the SubCategory | string | |
| Properties | Contains the display properties (color, style, weight, etc.) for the SubCategory. It should not be used for the persistence of application-specific information. | string | Json |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
Subject Sealed EntityClass
A bis:Subject is an information element that references (by name) some real-world Object that will be modeled in this BIS repository.
Base Class: BisCore:InformationReferenceElement
Subject elements only exist in the RepositoryModel singleton at the root of a BIS Repository. There will be one "root" instance of Subject that does not have a parent Subject. Child Subject elements reference "parts" of the real-world Object referenced by their parent Subject element.
The hierarchy of Subjects is not meant to model the root Object's structure, but is a way to express high-level structure that has not been modeled explicitly. Subjects do not "model" or "represent" or "describe" the Object that they reference. All modeling happens using Elements in the other bis:Models in the BIS Repository.
Behavior: The system handler (C++) for
Subjectwill only permit instances to be inserted into theRepositoryModel. It will require everySubjectexcept for the "root" to have itsParentproperty reference anotherSubject. The system handler also prevents the "root"Subjectfrom ever being deleted.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Description | A human-readable description of the real-world Object(s) that will be modeled for this Subject | string |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
SynchronizationConfigLink (Synchronization Configuration Link) EntityClass
Link to the Configuration for an iModel Synchronization Job
Base Class: BisCore:UrlLink
A Link to the Configuration for a Synchronization Job. By convention, a unique Id for the SynchronizationConfigLink such as a job Id should be set in the CodeValue property and a name should be set in in the UserLabel property.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| LastSuccessfulRun | Date/Time of Last Successful Run of this Synchronization Configuration | dateTime |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Url | A URL pointing to an external resource. | string | URI |
| Description | A human-readable description of the URL | string |
TemplateRecipe2d (2D Template Recipe) EntityClass
A recipe that uses a 2D template for creating new instances.
Base Class: BisCore:RecipeDefinitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
TemplateRecipe3d (3D Template Recipe) EntityClass
A recipe that uses a 3D template for creating new instances.
Base Class: BisCore:RecipeDefinitionElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
TemplateViewDefinition2d (2D Template View Definition) EntityClass
A bis:ViewDefinition2d used to display a 2D template model.
Base Class: BisCore:ViewDefinition2d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Description | A human-readable description of the View Definition | string | |
| CategorySelector | navigation | ||
| DisplayStyle | navigation | ||
| BaseModel | navigation | ||
| Origin | Lower left corner of the viewed area. | point2d | |
| Extents | Size of the view diagonal | point2d | |
| RotationAngle | Rotation angle in degrees of the viewed area. | double |
TemplateViewDefinition3d (3D Template View Definition) EntityClass
A bis:ViewDefinition3d used to display a 3D template model.
Base Class: BisCore:ViewDefinition3d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Description | A human-readable description of the View Definition | string | |
| CategorySelector | navigation | ||
| DisplayStyle | navigation | ||
| Origin | Origin of the viewed volume on the lower, back, rear | point3d | |
| Extents | Size of the view diagonal | point3d | |
| Yaw | Yaw component of the view direction in degrees | double | |
| Pitch | Pitch component of the view direction in degrees | double | |
| Roll | Roll component of the view direction in degrees | double | |
| IsCameraOn | Is the camera actually turned on? | boolean | |
| EyePoint | Camera eye point | point3d | |
| LensAngle | Camera lens angle in degrees | double | |
| FocusDistance | Camera focus distance | double |
TextAnnotation2d (2D Text Annotation) EntityClass
Base Class: BisCore:AnnotationElement2d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:DrawingCategory used to categorize this bis:GeometricElement2d instance. | navigation | |
| Origin | The placement origin of this bis:Element. | point2d | |
| Rotation | The placement rotation (in degrees) of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point2d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point2d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than by instance of this Element. | navigation |
TextAnnotation3d (3D Text Annotation) EntityClass
Base Class: BisCore:GraphicalElement3d
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:SpatialCategory used to categorize this bis:GeometricElement3d | navigation | |
| InSpatialIndex | If true, this element will have an entry in the Spatial Index. | boolean | |
| Origin | The placement origin of this bis:Element. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this bis:Element. | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this bis:Element. | double | |
| Roll | The Roll angle (in degrees) of the orientation of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point3d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point3d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than per-instance of this Element. | navigation |
TextAnnotationData (Text Annotation Data) Sealed EntityClass
The aspect used to store text annotation data for bis:TextAnnotation2d an bis:TextAnnotation3d elements.
Base Class: BisCore:ElementUniqueAspect
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| TextAnnotation | Text in Annotations.fb.h flat buffer format | binary |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Element | The bis:Element that owns this bis:ElementUniqueAspect | navigation |
TextAnnotationSeed (Text Annotation Seed) Sealed EntityClass
Base Class: BisCore:DefinitionElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Description | Description of the style | string | |
| Data | Encoded style properties | binary |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
Texture Sealed EntityClass
A bis:Texture represents a named texture used for rendering purposes. The texture data is stored as a binary blob interpreted according to the specified texture format.
Base Class: BisCore:DefinitionElement
Behavior: The system handler restricts deletion. A
Texturecan only be deleted via a more expensivedeleteDefinitionElementsmethod that has determined theTextureis no longer referenced.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Description | A human-readable description of the Texture | string | |
| Data | Encoded texture data | binary | |
| Format | Format of the encoded texture data. See the ImageSourceFormat enum in the API. | int | |
| Width | Image width in pixels. | int | |
| Height | Image height in pixels. | int | |
| Flags | Currently unused and always zero. | int |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
TypeDefinitionElement (Type Definition) Abstract EntityClass
Defines a shared set of properties (the 'type') that can be associated with a bis:Element.
Base Class: BisCore:DefinitionElement
A TypeDefinitionElement is an implementation of a data normalization strategy and is meant to hold properties that vary per type instead of varying per Element instance.
Rather than storing the same set of type-specific properties on every Element instance, each Element instance will have a set of instance-specific properties (as specified by the Element class) and a set of related type-specific properties found by joining to the TypeDefinitionElement instance.
See relationships such as PhysicalElementIsOfType.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Recipe | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
UrlLink (URL Link) EntityClass
A bis:UrlLink is a bis:LinkElement that specifies a URL link.
Base Class: BisCore:LinkElement
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Url | A URL pointing to an external resource. | string | URI |
| Description | A human-readable description of the URL | string |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
ViewAttachment (View Attachment) EntityClass
Base Class: BisCore:GraphicalElement2d
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| View | The view that is to be attached | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:DrawingCategory used to categorize this bis:GeometricElement2d instance. | navigation | |
| Origin | The placement origin of this bis:Element. | point2d | |
| Rotation | The placement rotation (in degrees) of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point2d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point2d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than by instance of this Element. | navigation |
ViewDefinition (View Definition) Abstract EntityClass
A bis:ViewDefinition specifies the area/volume that is viewed, and refers to a bis:DisplayStyle and a bis:CategorySelector to be used. Subclasses of bis:ViewDefinition determine which model(s) are viewed.
Base Class: BisCore:DefinitionElement
Behavior: The system handler (C++) for
ViewDefinitionrequires a validDisplayStylereference and a validCategorySelectorreference. This applies to allViewDefinitionsubclasses. The system handler also restricts deletion. AViewDefinitioncan only be deleted via a more expensivedeleteDefinitionElementsmethod that has determined theViewDefinitionis no longer referenced.
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Description | A human-readable description of the View Definition | string | |
| CategorySelector | navigation | ||
| DisplayStyle | navigation |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean |
ViewDefinition2d (2D View Definition) Abstract EntityClass
A view of a 2D model that has its own local coordinate system.
Base Class: BisCore:ViewDefinition
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| BaseModel | navigation | ||
| Origin | Lower left corner of the viewed area. | point2d | |
| Extents | Size of the view diagonal | point2d | |
| RotationAngle | Rotation angle in degrees of the viewed area. | double |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Description | A human-readable description of the View Definition | string | |
| CategorySelector | navigation | ||
| DisplayStyle | navigation |
ViewDefinition3d (3D View Definition) Abstract EntityClass
A bis:ViewDefinition3d specifies the volume that is viewed on referenced 3D bis:Models. It refers to a bis:DisplayStyle3d and a bis:CategorySelector to be used.
Base Class: BisCore:ViewDefinition
Properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Origin | Origin of the viewed volume on the lower, back, rear | point3d | |
| Extents | Size of the view diagonal | point3d | |
| Yaw | Yaw component of the view direction in degrees | double | |
| Pitch | Pitch component of the view direction in degrees | double | |
| Roll | Roll component of the view direction in degrees | double | |
| IsCameraOn | Is the camera actually turned on? | boolean | |
| EyePoint | Camera eye point | point3d | |
| LensAngle | Camera lens angle in degrees | double | |
| FocusDistance | Camera focus distance | double |
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| IsPrivate | If true, this bis:DefinitionElement should not be displayed in the GUI. | boolean | |
| Description | A human-readable description of the View Definition | string | |
| CategorySelector | navigation | ||
| DisplayStyle | navigation |
VolumeElement (Volume Element) EntityClass
A bis:VolumeElement is a bis:SpatialLocationElement that is restricted to defining a volume.
Base Class: BisCore:SpatialLocationElement
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| Model | The bis:Model that contains this bis:Element. | navigation | |
| LastMod | The last modified time of the bis:Element. This is maintained by the core framework and should not be set directly by applications. | dateTime | |
| CodeSpec | The CodeSpec property identifies the bis:CodeSpec used to generate and validate the code value for this bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeScope | The CodeScope property identifies the bis:Element that provides the uniqueness scope for the code value. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | navigation | |
| CodeValue | The CodeValue property stores a human-readable real-world identifier of the Entity represented by the bis:Element. The combination of CodeSpec, CodeScope, and CodeValue properties must be unique for each bis:Element instance. | string | |
| UserLabel | An optional friendly name given by the user (as opposed to the formal name stored in the CodeValue property). | string | |
| Parent | The parent bis:Element that owns this bis:Element. | navigation | |
| FederationGuid | The GUID used to federate this bis:Element across repositories. | binary | BeGuid |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| Category | The bis:SpatialCategory used to categorize this bis:GeometricElement3d | navigation | |
| InSpatialIndex | If true, this element will have an entry in the Spatial Index. | boolean | |
| Origin | The placement origin of this bis:Element. | point3d | |
| Yaw | The Yaw angle (in degrees) of the orientation of this bis:Element. | double | |
| Pitch | The Pitch angle (in degrees) of the orientation of this bis:Element. | double | |
| Roll | The Roll angle (in degrees) of the orientation of this bis:Element. | double | |
| BBoxLow | The 'low' point of the element-aligned bounding box of this bis:Element. | point3d | |
| BBoxHigh | The 'high' point of the element-aligned bounding box of this bis:Element. | point3d | |
| GeometryStream | Binary stream used to persist the geometry of this bis:Element. | binary | GeometryStream |
| TypeDefinition | Points to an instance of some specialization of TypeDefinition, which holds property values that vary per-type rather than per-instance of this Element. | navigation |
WebMercatorModel (Web Mercator Model) EntityClass Deprecated
DEPRECATED. Not used.
Base Class: BisCore:SpatialModel
Inherited properties
| Name | Description | Type | Extended Type |
|---|---|---|---|
| ParentModel | The parent bis:Model contains the bis:Element that this bis:Model is sub-modeling. | navigation | |
| ModeledElement | The bis:Element that this bis:Model is sub-modeling. This bis:Model models the same Entity as the sub-Modeled bis:Element, but at a finer granularity. | navigation | |
| IsPrivate | If IsPrivate is true then this bis:Model should not appear in lists shown to the user. | boolean | |
| IsTemplate | If IsTemplate is true then this bis:Model is used as a template for creating new instances. | boolean | |
| JsonProperties | A string property that users and/or applications can use to persist ad hoc JSON values. | string | Json |
| LastMod | The last time any element in this Model was modified. | dateTime | |
| GeometryGuid | A GUID that changes whenever any element in this GeometricModel has a change to its geometry. | binary | BeGuid |
| IsNotSpatiallyLocated | If IsNotSpatiallyLocated is true, then the elements in this bis:GeometricModel3d are not in real-world coordinates and will not be in the spatial index. | boolean | |
| IsPlanProjection | If IsPlanProjection is true, then the elements in this bis:GeometricModel3d are expected to be in an XY plane. | boolean |
Mixins
IParentElement (Parent Element) Abstract Mixin
An interface that can be mixed-into a bis:Element to indicate that it can be a parent (own child Elements). This interface is mutually exclusive with bis:ISubModeledElement.
Applies To: Element
Only subclasses of bis:Element can implement the IParentElement interface
Parent-child modeling differs from sub-modeling in that the parent Element and child Elements are to be considered together in the context of a single Model, whereas a sub-modeled Element is considered independently of its sub-Model. For example, and application would view a parent Element and its child Elements together, but would either view a sub-modeled Element or exclude that Element and instead view the Elements of its sub-Model.
See also ISubModeledElement.
ISubModeledElement (Sub-Modeled Element) Abstract Mixin
An interface that can be mixed-into a bis:Element to indicate that it can be sub-modeled by a finer-grained bis:Model. This interface is mutually exclusive with bis:IParentElement.
Applies To: Element
Sub-modeling is also sometimes described as "breaking down", i.e. a sub-modeled Element can be "broken down into" a finer-grained (sub) Model.
See also IParentElement.
Behavior: The system handler (C++) for
Elementonly permits a sub-model to be inserted if the class of the modeled element implements theISubModeledElementinterface.
Custom Attribute Classes
AutoHandledProperty CustomAttributeClass
Applied to an element's property to indicate that select, update, and insert of the property's value are handled automatically by the platform.
Applies to: AnyProperty
Properties
| Name | Description | Label | Category | Read Only | Priority |
|---|---|---|---|---|---|
| StatementTypes | Indicates the statement types that are relevant for a particular auto-handled property. | false | 0 |
ClassHasHandler CustomAttributeClass
Applied to an ECClass to indicate that a C++ subclass of DgnDomain::Handler will supply behavior for it at run-time. This custom attribute may only be used by BisCore or other core schemas.
Applies to: Any
Applied to an ECClass to indicate that a system handler (written in C++) will supply behavior for it at run-time.
This custom attribute may only be used by BisCore and other core schemas.
Other schemas should use domain handlers (written in TypeScript) and the SchemaHasBehavior custom attribute applied to the ECSchema instead.
Properties
| Name | Description | Label | Category | Read Only | Priority |
|---|---|---|---|---|---|
| Restrictions | List of actions that are not permitted when the associated handler is not available | false | 0 |
CustomHandledProperty CustomAttributeClass
Applied to an element's property to indicate that the property's value is handled specially by a C++ class. Can only be applied to properties of ECClasses that specify ClassHasHandler.
Applies to: AnyProperty
See CustomHandledPropertyStatementType.
Properties
| Name | Description | Label | Category | Read Only | Priority |
|---|---|---|---|---|---|
| StatementTypes | Indicates the statement types that are relevant for a particular custom-handled property. | false | 0 |
ReservedPropertyNames Sealed CustomAttributeClass
Declare a list of properties as reserved. The property name listed would be forbidden from use in the class and classes that inherit from it.
Applies to: EntityClass, RelationshipClass
Properties
| Name | Description | Label | Category | Read Only | Priority |
|---|---|---|---|---|---|
| PropertyNames | An array of names of properties that should not be used. Case-insensitive comparison will be used. | false | 0 |
SchemaHasBehavior CustomAttributeClass
Applied to an ECSchema to indicate that there is an associated JavaScript library that will provide run-time behavior.
Applies to: Schema
Properties
| Name | Description | Label | Category | Read Only | Priority |
|---|---|---|---|---|---|
| Restrictions | List of actions that are not permitted when the associated JavaScript library is not available. | false | 0 |
Relationship Classes
BaseModelForView2d Sealed RelationshipClass
Strength: Referencing
Strength Direction: Forward
See ViewDefinition2d.BaseModel ECNavigationProperty ECNavigationProperty
Source
Target
CategoryOwnsSubCategories RelationshipClass
Base Class: BisCore:ElementOwnsChildElements
Strength: Embedding
Strength Direction: Forward
Source
Target
CategorySelectorRefersToCategories Sealed RelationshipClass
Base Class: BisCore:ElementRefersToElements
Strength: Referencing
Strength Direction: Forward
Source
Target
CodeSpecSpecifiesCode Sealed RelationshipClass
Strength: Referencing
Strength Direction: Forward
See Element.CodeSpec ECNavigationProperty.
Source
Target
DefinitionGroupGroupsDefinitions RelationshipClass
A relationship used to identify the DefinitionsElements that are members of a DefinitionGroup.
Base Class: BisCore:ElementGroupsMembers
Strength: Referencing
Strength Direction: Forward
A DefinitionGroup may not be both the source and the target of the same relationship instance.
Source
Target
DrawingGraphicRepresentsElement RelationshipClass
Relates a bis:DrawingGraphic to the bis:Element that it represents.
Base Class: BisCore:ElementRefersToElements
Strength: Referencing
Strength Direction: Forward
Source
Target
DrawingModelBreaksDownDrawing (DrawingModel Sub-Models Drawing) RelationshipClass
Base Class: BisCore:ModelModelsElement
Strength: Embedding
Strength Direction: Backward
A more consistent name for this relationship would have been 'DrawingModelSubModelsDrawing', but the existing name cannot be changed in this generation of BIS. At times, we use "breaks down" as a synonym for "sub-models", but we are standardizing on "sub-models", reserving "breakdown" for use with various engineering breakdown structures.
Source
Target
ElementDrivesElement RelationshipClass
A relationship that indicates that the source Element drives (controls the lifecycle or structure of) a dependent target Element.
Strength: Referencing
Strength Direction: Forward
In iModels, a change-propagation system calls handlers that allow the driven Element to be affected by the driving Element. See DriverBundleElement.
Source
Target
ElementEncapsulatesElements RelationshipClass
A relationship that indicates that child bis:Elements are meant to be hidden.
Base Class: BisCore:ElementOwnsChildElements
Strength: Embedding
Strength Direction: Forward
Source
Target
ElementGroupsMembers RelationshipClass
Represents group membership. Relates a group Element to its member Elements.
Base Class: BisCore:ElementRefersToElements
Strength: Referencing
Strength Direction: Forward
Source
Target
ElementHasLinks RelationshipClass
Associates bis:LinkElements to a bis:Element.
Base Class: BisCore:ElementRefersToElements
Strength: Referencing
Strength Direction: Forward
Source
Target
ElementIsFromSource Sealed RelationshipClass
Relates an Element (via its ExternalSourceAspect) with its ExternalSource. Used as an ECNavigationProperty by bis:ExternalSourceAspect.Source.
Strength: Referencing
Strength Direction: Forward
Source
Target
ElementOwnsChannelRootAspect RelationshipClass
Base Class: BisCore:ElementOwnsUniqueAspect
Strength: Embedding
Strength Direction: Forward
Source
Target
ElementOwnsChildElements RelationshipClass
Relates a bis:Element to child bis:Elements which represent parts of the Entity modeled by the parent bis:Element.
Strength: Embedding
Strength Direction: Forward
See Element.Parent ECNavigationProperty ECNavigationProperty Should be treated as abstract, but was not made abstract because of legacy usages that were already released.
Source
Target
ElementOwnsExternalSourceAspects RelationshipClass
Base Class: BisCore:ElementOwnsMultiAspects
Strength: Embedding
Strength Direction: Forward
Source
Target
ElementOwnsMultiAspects RelationshipClass
Strength: Embedding
Strength Direction: Forward
See ElementMultiAspect.Element ECNavigationProperty ECNavigationProperty
Source
Target
ElementOwnsUniqueAspect RelationshipClass
Strength: Embedding
Strength Direction: Forward
See ElementUniqueAspect.Element ECNavigationProperty ECNavigationProperty
Source
Target
ElementRefersToDocuments RelationshipClass
A general relationship between a bis:Element and a bis:Document. There is no implied owner in this relationship – so it is valid for relationship where the document existed before the referenced element (e.g. design specification) or after (e.g. operational results).
Base Class: BisCore:ElementRefersToElements
Strength: Referencing
Strength Direction: Forward
Source
Target
ElementRefersToElements Abstract RelationshipClass
A general relationship between two bis:Elements. These are typically specialized by derived relationship to give more specific meaning.
Strength: Referencing
Strength Direction: Forward
Subclasses of ElementRefersToElements can make use of the MemberPriority property to prioritize or order elements being referenced. By default, MemberPriority is set to null if not assigned. Duplicate not-null values for MemberPriority are allowed as long as the Sources, Targets, or the ECClassId of the relationships are different. Furthermore, duplicate Sources and Targets are accepted only if either their ECClassId or MemberPriority values are not the same.
Source
Target
ElementScopesCode Sealed RelationshipClass
Strength: Referencing
Strength Direction: Forward
See Element.CodeScope ECNavigationProperty.
Source
Target
ElementScopesExternalSourceIdentifier Sealed RelationshipClass
Used by ECNavigationProperty bis:ExternalSourceAspect.Scope
Strength: Referencing
Strength Direction: Backward
Source
Target
ExternalSourceAttachmentAttachesSource RelationshipClass
Used by ECNavigationProperty bis:ExternalSourceAttachment.Attaches
Strength: Referencing
Strength Direction: Forward
Source
Target
ExternalSourceGroupGroupsSources Sealed RelationshipClass
Groups ExternalSources that collectively act as a source used by an ExternalSourceAspect.
Base Class: BisCore:ElementGroupsMembers
Strength: Referencing
Strength Direction: Forward
Source
Target
ExternalSourceIsInRepository Sealed RelationshipClass
Used by ExternalSource.Repository ECNavigationProperty
Strength: Referencing
Strength Direction: Forward
Source
Target
ExternalSourceOwnsAttachments RelationshipClass
Relationship between an external source and its attachments
Base Class: BisCore:ElementOwnsChildElements
Strength: Embedding
Strength Direction: Forward
Source
Target
FolderContainsRepositories (Folder Contains Repositories) RelationshipClass
Relationship between a Folder and the Repositories which it contains
Base Class: BisCore:ElementOwnsChildElements
Strength: Embedding
Strength Direction: Forward
Source
Target
GeometricElement2dHasTypeDefinition Abstract RelationshipClass
Strength: Referencing
Strength Direction: Forward
See GeometricElement2d.TypeDefinition ECNavigationProperty ECNavigationProperty
Source
Target
GeometricElement2dIsInCategory Sealed RelationshipClass
The relationship that determines the bis:DrawingCategory for a bis:GeometricElement2d.
Strength: Referencing
Strength Direction: Backward
Source
Target
GeometricElement3dHasTypeDefinition Abstract RelationshipClass
Strength: Referencing
Strength Direction: Forward
See GeometricElement3d.TypeDefinition ECNavigationProperty ECNavigationProperty
Source
Target
GeometricElement3dIsInCategory Sealed RelationshipClass
The relationship that determines the bis:SpatialCategory for a bis:GeometricElement3d.
Strength: Referencing
Strength Direction: Backward
Source
Target
GraphicalElement2dIsOfType RelationshipClass
Base Class: BisCore:GeometricElement2dHasTypeDefinition
Strength: Referencing
Strength Direction: Forward
Source
Target
GraphicalElement3dRepresentsElement RelationshipClass
Relates a bis:GraphicalElement3d to the bis:Element that it represents.
Base Class: BisCore:ElementRefersToElements
Strength: Referencing
Strength Direction: Forward
Source
Target
GraphicalType2dHasTemplateRecipe RelationshipClass
Base Class: BisCore:TypeDefinitionHasRecipe
Strength: Referencing
Strength Direction: Forward
Source
Target
GroupImpartsToMembers RelationshipClass
Represents group membership where the group Element (and its properties) impart information about the member Elements above mere membership. Implies that properties of the group should be considered as properties of its members.
Base Class: BisCore:ElementGroupsMembers
Strength: Referencing
Strength Direction: Forward
Source
Target
ModelContainsElements Sealed RelationshipClass
The relationship that enforces that each bis:Element belongs to exactly one bis:Model.
Strength: Embedding
Strength Direction: Forward
See Element.Model ECNavigationProperty.
Source
Target
ModelModelsElement (Model Sub-Models Element) RelationshipClass
Relates a bis:Model to the bis:Element that it sub-models. The sub-Model models the same Entity as the sub-modeled Element, but at a finer granularity.
Strength: Embedding
Strength Direction: Backward
See Model.ModeledElement ECNavigationProperty.
A more accurate name for this relationship would have been 'ModelSubModelsElement', but the existing name cannot be changed in this generation of BIS.
Source
Target
ModelOwnsSubModel Sealed RelationshipClass
This relationship is essentially redundant with the combination of bis:ModelModelsElement and bis:ModelContainsElements. This 'shortcut' exists to support a model hierarchy index for performance reasons.
Strength: Embedding
Strength Direction: Forward
See Model.ParentModel ECNavigationProperty.
Source
Target
ModelSelectorRefersToModels Sealed RelationshipClass
PartitionOriginatesFromRepository Sealed RelationshipClass Deprecated
DEPRECATED: Use ElementHasLinks
Base Class: BisCore:ElementRefersToElements
Strength: Referencing
Strength Direction: Forward
Source
Target
PhysicalElementAssemblesElements RelationshipClass
A relationship that indicates a physical assembly of child bis:PhysicalElements.
Base Class: BisCore:ElementOwnsChildElements
Strength: Embedding
Strength Direction: Forward
Source
Target
PhysicalElementIsOfPhysicalMaterial Sealed RelationshipClass
A relationship indicating the bis:PhysicalMaterial of which the bis:PhysicalElement is made.
Strength: Referencing
Strength Direction: Forward
Source
Target
PhysicalElementIsOfType RelationshipClass
A type-instance relation; one that indicates that the specific bis:PhysicalElement is an instance of the defined bis:PhysicalType. E.g. a pump with serial number #AR-23 is of type X-Model-Y.
Base Class: BisCore:GeometricElement3dHasTypeDefinition
Strength: Referencing
Strength Direction: Forward
Source
Target
PhysicalModelBreaksDownPhysicalPortion RelationshipClass Deprecated
DEPRECATED
Base Class: BisCore:ModelModelsElement
Strength: Embedding
Strength Direction: Backward
Source
Target
PhysicalSystemAggregatesSubSystems (Physical System Aggregates Sub-Systems) RelationshipClass
Forms the Physical System hierarchy.
Strength: Referencing
Strength Direction: Forward
Forms a strict hierarchy (A PhysicalSystem can only be aggregated by a single 'aggregator').
See PhysicalSystem for more information.
Source
Target
PhysicalSystemGroupsMembers (Physical System Groups Spatial Elements) RelationshipClass
A relationship used to identify the bis:PhysicalElements that are members of a PhysicalSystem.
Base Class: BisCore:ElementGroupsMembers
Strength: Referencing
Strength Direction: Forward
Source
Target
PhysicalSystemServicesSpatialElements (Physical System Services Spatial Elements) RelationshipClass
A relationship used to identify the bis:SpatialElements serviced by a PhysicalSystem.
Base Class: BisCore:ElementRefersToElements
Strength: Referencing
Strength Direction: Forward
Source
Target
PhysicalTypeHasTemplateRecipe RelationshipClass
Base Class: BisCore:TypeDefinitionHasRecipe
Strength: Referencing
Strength Direction: Forward
Source
Target
PhysicalTypeIsOfPhysicalMaterial Sealed RelationshipClass
A relationship indicating the bis:PhysicalMaterial of which bis:PhysicalElements of the given bis:PhysicalType are made. Can be overridden with bis:PhysicalElementIsOfPhysicalMaterial.
Strength: Referencing
Strength Direction: Forward
Source
Target
RenderMaterialOwnsRenderMaterials RelationshipClass
Base Class: BisCore:ElementOwnsChildElements
Strength: Embedding
Strength Direction: Forward
Source
Target
SectionDrawingGeneratedFromSpatialView Sealed RelationshipClass
Identifies the SpatialViewDefinition used to generate the SectionDrawing.
Strength: Referencing
Strength Direction: Backward
Source
Target
SectionDrawingLocationRefersToSectionView Sealed RelationshipClass
Relates a SectionDrawingLocation to the view generated by the section's SpatialViewDefinition.
Strength: Referencing
Strength Direction: Backward
Source
Target
SectionLocationRefersToViewAttachment Sealed RelationshipClass Deprecated
DEPRECATED: Relates a SectionLocation to a ViewAttachment placing the section's DrawingViewDefinition onto a Sheet.
Strength: Referencing
Strength Direction: Backward
Source
Target
SectionLocationUsesCategorySelector Sealed RelationshipClass Deprecated
DEPRECATED: Relates a SectionLocation to the categories relevant for this SectionLocation display.
Strength: Referencing
Strength Direction: Forward
See SectionLocation.CategorySelector ECNavigationProperty ECNavigationProperty
Source
Target
SectionLocationUsesModelSelector Sealed RelationshipClass Deprecated
DEPRECATED: Relates a SectionLocation to the models relevant for this SectionLocation display.
Strength: Referencing
Strength Direction: Forward
Source
Target
SheetBorderHasSheetBorderTemplate Sealed RelationshipClass
Strength: Referencing
Strength Direction: Forward
See SheetBorder.BorderTemplate ECNavigationProperty ECNavigationProperty
Source
Target
SheetHasSheetTemplate Sealed RelationshipClass
Strength: Referencing
Strength Direction: Forward
See Sheet.SheetTemplate ECNavigationProperty ECNavigationProperty
Source
Target
SheetIndexFolderOwnsEntries RelationshipClass
Base Class: BisCore:ElementOwnsChildElements
Strength: Embedding
Strength Direction: Forward
Source
Target
SheetIndexOwnsEntries RelationshipClass
Base Class: BisCore:ElementOwnsChildElements
Strength: Embedding
Strength Direction: Forward
Source
Target
SheetIndexReferenceRefersToSheetIndex Sealed RelationshipClass
Strength: Referencing
Strength Direction: Forward
See SheetIndexReference.SheetIndex ECNavigationProperty ECNavigationProperty
Source
Target
SheetModelBreaksDownSheet (SheetModel Sub-Models Sheet) RelationshipClass
Base Class: BisCore:ModelModelsElement
Strength: Embedding
Strength Direction: Backward
A more consistent name for this relationship would have been 'SheetModelSubModelsSheet', but the existing name cannot be changed in this generation of BIS. At times, we use "breaks down" as a synonym for "sub-models", but we are standardizing on "sub-models", reserving "breakdown" for use with various engineering breakdown structures.
Source
Target
SheetReferenceRefersToSheet Sealed RelationshipClass
Strength: Referencing
Strength Direction: Forward
See SheetReference.Sheet ECNavigationProperty ECNavigationProperty
Source
Target
SheetTemplateHasSheetBorder Sealed RelationshipClass
Strength: Referencing
Strength Direction: Forward
See SheetTemplate.Border ECNavigationProperty ECNavigationProperty
Source
Target
SpatialLocationIsOfType RelationshipClass
A type-instance relation; one that indicates that the specific bis:SpatialLocationElement is an instance of the defined bis:SpatialLocationType. E.g. AssemblyArea#5 if of type FloorSpace.
Base Class: BisCore:GeometricElement3dHasTypeDefinition
Strength: Referencing
Strength Direction: Forward
Source
Target
SpatialViewDefinitionUsesModelSelector Sealed RelationshipClass
Strength: Referencing
Strength Direction: Forward
See SpatialViewDefinition.ModelSelector ECNavigationProperty ECNavigationProperty
Source
Target
SubjectOwnsPartitionElements RelationshipClass
Base Class: BisCore:ElementOwnsChildElements
Strength: Embedding
Strength Direction: Forward
Source
Target
SubjectOwnsSubjects RelationshipClass
Base Class: BisCore:ElementOwnsChildElements
Strength: Embedding
Strength Direction: Forward
Source
Target
SubjectRefersToSubject RelationshipClass
A relationship allowing a bis:Subject to express association with another bis:Subject that is not one of its children.
Base Class: BisCore:ElementRefersToElements
Strength: Referencing
Strength Direction: Forward
A bis:Subject can be referenced by zero or more bis:Subject instances as opposed to the bis:SubjectOwnsSubjects relationship that leads to a strict hierarchy. This relationship is typically needed when the referencing and referenced bis:Subjects are located in different branches of the Subject hierarchy. With this relationship, the referencing bis:Subject is stating an association with the referenced bis:Subjects without duplicating them into its own branch. The concrete semantics behind such association is left for the data-writer or a human being to interpret, as it is generally the case with all bis:Subject instances on the Subject hierarchy as a whole.
Source
Target
SynchronizationConfigProcessesSources RelationshipClass
Records the ExternalSources processed according to a given configuration. These sources may be 'discovered' via the 'root' sources specified by bis:SynchronizationConfigSpecifiesRootSources. ExternalSources can be processed by more than one SynchronizationConfig.
Base Class: BisCore:ElementRefersToElements
Strength: Referencing
Strength Direction: Forward
Source
Target
SynchronizationConfigSpecifiesRootSources Sealed RelationshipClass
Records the 'root' ExternalSources specified by the configuration. These roots are used to discovered other 'referenced' sources and they serve as roots of 'referencing trees' for GUI display.
Base Class: BisCore:SynchronizationConfigProcessesSources
Strength: Referencing
Strength Direction: Forward
Source
Target
TextAnnotation2dOwnsTextAnnotationData RelationshipClass
Base Class: BisCore:ElementOwnsUniqueAspect
Strength: Embedding
Strength Direction: Forward
Source
Target
TextAnnotation3dOwnsTextAnnotationData RelationshipClass
Base Class: BisCore:ElementOwnsUniqueAspect
Strength: Embedding
Strength Direction: Forward
Source
Target
TypeDefinitionHasRecipe Abstract RelationshipClass
Strength: Referencing
Strength Direction: Forward
See TypeDefinitionElement.Recipe ECNavigationProperty ECNavigationProperty
Source
Target
ViewDefinitionUsesCategorySelector Sealed RelationshipClass
Strength: Referencing
Strength Direction: Forward
See ViewDefinition.CategorySelector ECNavigationProperty ECNavigationProperty
Source
Target
ViewDefinitionUsesDisplayStyle Sealed RelationshipClass
Strength: Referencing
Strength Direction: Forward
See ViewDefinition.DisplayStyle ECNavigationProperty ECNavigationProperty
Source
Target
ViewIsAttached Sealed RelationshipClass
Strength: Referencing
Strength Direction: Forward
See ViewAttachment.View ECNavigationProperty ECNavigationProperty
Source
Target
Enumerations
AutoHandledPropertyStatementType Enumeration
Backing Type: int
Strict: true
| Label | Value | Description |
|---|---|---|
| ReadOnly = Select|Insert | 3 | |
| All = Select | Insert | Update | 7 |
Restrictions that may be applied to an AutoHandledProperty. Must match the ECSqlClassParams::StatementType enum
CustomHandledPropertyStatementType Enumeration
Backing Type: int
Restrictions that may be applied to a CustomHandledProperty. Must match the ECSqlClassParams::StatementType enum
Strict: true
| Label | Value | Description |
|---|---|---|
| None | 0 | |
| Select | 1 | |
| Insert | 2 | |
| ReadOnly = Select|Insert | 3 | |
| Update | 4 | |
| InsertUpdate = Insert | Update | 6 | |
| All = Select | Insert | Update | 7 |
ExternalSourceAttachmentRole (External Source Attachment Role) Enumeration
Backing Type: int
The role that an attached ExternalSource plays, e.g. to specify context or a part-of-a-whole. Used by bis:ExternalSource.Role
Strict: true
| Label | Value | Description |
|---|---|---|
| Specify Context | 0 | |
| Specify Part | 1 |
SectionType Enumeration
Backing Type: int
Strict: false
| Label | Value | Description |
|---|---|---|
| Section | 3 | |
| Detail | 4 | |
| Elevation | 5 | |
| Plan | 6 |
Last Updated: 28 June, 2024
